GPU Kernel Programming for LLM Optimization

The fastest code is the code the GPU never has to wait for.

Quant, Kernel Obsessed AI Agent

1. Why Custom Kernels Matter

A standard PyTorch attention implementation performs four separate GPU operations: matrix multiplication (Q @ K^T), scaling, softmax, and another matrix multiplication (scores @ V). Each operation launches a separate kernel, and each kernel reads its inputs from HBM (High Bandwidth Memory, the GPU's main memory) and writes its outputs back to HBM. For a sequence length of 8,192 and a hidden dimension of 4,096, the attention scores matrix alone is 8192 x 8192 x 2 bytes = 128 MB. This matrix is written to HBM by the first kernel and read back by the softmax kernel, even though it is a temporary intermediate that is never needed again.

The key insight is that modern GPUs are memory-bandwidth-bound for most LLM operations, not compute-bound. An NVIDIA A100 can perform 312 TFLOPS of FP16 computation but can only move data at 2 TB/s. The ratio of compute to memory bandwidth (the arithmetic intensity threshold) is about 156 FLOPs per byte. Any operation that performs fewer than 156 FLOPs for each byte it reads or writes is bottlenecked by memory, not compute. Most element-wise operations (activation functions, layer normalization, dropout) fall far below this threshold.

Custom kernels solve this by keeping intermediate results in SRAM (the GPU's fast on-chip memory, roughly 20 MB on an A100) and performing multiple operations before writing back to HBM. This technique is called kernel fusion, and it is the foundation of FlashAttention, fused layer normalization, and most other high-performance LLM kernels.

1.1 Arithmetic Intensity Analysis

Before writing a custom kernel, you should determine whether the operation is worth optimizing. The arithmetic intensity of an operation is defined as:

For an element-wise operation like GELU activation on a tensor of $n$ elements (FP16), the computation requires roughly $10n$ FLOPs while reading $2n$ bytes and writing $2n$ bytes, giving an arithmetic intensity of $10n / 4n = 2.5$ FLOPs/byte. This is far below the A100's threshold of 156, making it heavily memory-bound and an excellent candidate for fusion with adjacent operations.

For a matrix multiplication of shapes $(M, K) \times (K, N)$, the computation requires $2MKN$ FLOPs while transferring $2(MK + KN + MN)$ bytes, giving an arithmetic intensity that grows with matrix size. Large GEMM operations in LLMs are typically compute-bound and well-served by cuBLAS; the opportunity for custom kernels lies in the surrounding element-wise and reduction operations.

# Arithmetic intensity calculator for common LLM operations
# Use this to decide whether a custom kernel is worthwhile

import torch

def arithmetic_intensity(op_name, M=4096, N=4096, K=4096, dtype_bytes=2):
 """Calculate FLOPs/byte for common operations on an MxN matrix."""
 if op_name == "gelu":
 # Element-wise: ~10 FLOPs per element, read + write
 flops = 10 * M * N
 bytes_transferred = 2 * dtype_bytes * M * N # read + write
 elif op_name == "layernorm":
 # Two passes (mean, variance) + normalize: ~8 FLOPs per element
 flops = 8 * M * N
 bytes_transferred = 2 * dtype_bytes * M * N
 elif op_name == "softmax":
 # Max reduction + exp + sum reduction + divide: ~8 FLOPs per element
 flops = 8 * M * N
 bytes_transferred = 2 * dtype_bytes * M * N
 elif op_name == "matmul":
 # 2*M*K*N FLOPs, read A(M,K) + B(K,N) + write C(M,N)
 flops = 2 * M * K * N
 bytes_transferred = dtype_bytes * (M * K + K * N + M * N)
 elif op_name == "fused_attention":
 # Q@K^T + scale + softmax + @V, but intermediate stays in SRAM
 # Only reads Q, K, V and writes output
 flops = 2 * M * K * N + 8 * M * N + 2 * M * K * N
 bytes_transferred = dtype_bytes * (3 * M * K + M * K) # Q,K,V in + O out
 else:
 raise ValueError(f"Unknown operation: {op_name}")

 intensity = flops / bytes_transferred
 a100_threshold = 156 # FLOPs/byte for A100 at FP16
 bound = "COMPUTE" if intensity > a100_threshold else "MEMORY"

 print(f"{op_name:>20}: {intensity:8.1f} FLOPs/byte [{bound}-bound]")
 return intensity

# Compare operations at typical LLM dimensions
print(f"{'Operation':>20} {'Intensity':>8} Bottleneck")
print("-" * 50)
for op in ["gelu", "layernorm", "softmax", "matmul", "fused_attention"]:
 arithmetic_intensity(op)

# FlashAttention conceptual implementation in Triton (simplified)
# Production code: use flash_attn package or torch SDPA

import torch
import triton
import triton.language as tl

@triton.jit
def flash_attention_fwd_kernel(
 Q_ptr, K_ptr, V_ptr, O_ptr,
 stride_qm, stride_qd,
 stride_kn, stride_kd,
 stride_vn, stride_vd,
 stride_om, stride_od,
 seq_len, head_dim,
 scale,
 BLOCK_M: tl.constexpr, # tile size for queries
 BLOCK_N: tl.constexpr, # tile size for keys/values
 BLOCK_D: tl.constexpr, # head dimension (must cover full d)
):
 # Each program handles one BLOCK_M-sized tile of queries
 pid_m = tl.program_id(0)
 start_m = pid_m * BLOCK_M

 # Initialize accumulators in SRAM
 m_offsets = start_m + tl.arange(0, BLOCK_M)
 d_offsets = tl.arange(0, BLOCK_D)

 # Running softmax statistics (online softmax trick)
 m_i = tl.full([BLOCK_M], value=-float("inf"), dtype=tl.float32) # running max
 l_i = tl.zeros([BLOCK_M], dtype=tl.float32) # running sum of exp
 acc = tl.zeros([BLOCK_M, BLOCK_D], dtype=tl.float32) # output accumulator

 # Load Q tile (stays in SRAM for all K/V tiles)
 q_ptrs = Q_ptr + m_offsets[:, None] * stride_qm + d_offsets[None, :] * stride_qd
 q_mask = m_offsets[:, None] < seq_len
 q = tl.load(q_ptrs, mask=q_mask, other=0.0)

 # Iterate over all K/V tiles
 for start_n in range(0, seq_len, BLOCK_N):
 n_offsets = start_n + tl.arange(0, BLOCK_N)

 # Load K tile
 k_ptrs = K_ptr + n_offsets[:, None] * stride_kn + d_offsets[None, :] * stride_kd
 k_mask = n_offsets[:, None] < seq_len
 k = tl.load(k_ptrs, mask=k_mask, other=0.0)

 # Compute attention scores for this tile: [BLOCK_M, BLOCK_N]
 scores = tl.dot(q, tl.trans(k)) * scale

 # Online softmax update
 m_new = tl.maximum(m_i, tl.max(scores, axis=1))
 alpha = tl.exp(m_i - m_new)
 p = tl.exp(scores - m_new[:, None])

 # Rescale previous accumulator and add new contribution
 l_i = l_i * alpha + tl.sum(p, axis=1)
 acc = acc * alpha[:, None]

 # Load V tile and accumulate
 v_ptrs = V_ptr + n_offsets[:, None] * stride_vn + d_offsets[None, :] * stride_vd
 v = tl.load(v_ptrs, mask=n_offsets[:, None] < seq_len, other=0.0)
 acc += tl.dot(p.to(tl.float16), v)

 m_i = m_new

 # Final normalization
 acc = acc / l_i[:, None]

 # Write output tile to HBM
 o_ptrs = O_ptr + m_offsets[:, None] * stride_om + d_offsets[None, :] * stride_od
 o_mask = m_offsets[:, None] < seq_len
 tl.store(o_ptrs, acc.to(tl.float16), mask=o_mask)

print("FlashAttention kernel defined (see flash_attn package for production use)")

2. Triton: Python-Based GPU Kernel Programming

Triton, developed by OpenAI, lets you write GPU kernels in Python with a programming model centered on block-level operations. Unlike CUDA, where you think in terms of individual threads, Triton operates on tiles (blocks) of data. The compiler handles thread scheduling, memory coalescing, and shared memory management automatically. This dramatically reduces the complexity of writing correct, high-performance GPU code.

The core abstraction in Triton is the block pointer. Instead of computing a single output element per thread, a Triton kernel computes an entire block of output elements. The programmer specifies the block size (e.g., BLOCK_SIZE=1024), and Triton's compiler maps this to an efficient thread configuration. The programmer's job is to describe the data flow at the block level; the compiler's job is to make it fast.

2.1 A First Triton Kernel: Vector Addition

This snippet writes a simple Triton kernel that performs element-wise vector addition on the GPU.

# Triton vector addition kernel
# The simplest possible Triton kernel, showing the block programming model

import torch
import triton
import triton.language as tl

@triton.jit
def vector_add_kernel(
 x_ptr, # pointer to first input vector
 y_ptr, # pointer to second input vector
 output_ptr, # pointer to output vector
 n_elements, # total number of elements
 BLOCK_SIZE: tl.constexpr, # number of elements per block (compile-time)
):
 # Each program instance handles one block of BLOCK_SIZE elements.
 # pid tells us which block we are.
 pid = tl.program_id(axis=0)

 # Compute the range of indices this block handles
 block_start = pid * BLOCK_SIZE
 offsets = block_start + tl.arange(0, BLOCK_SIZE)

 # Mask out-of-bounds accesses (last block may be partial)
 mask = offsets < n_elements

 # Load a block of data from each input (block-level load)
 x = tl.load(x_ptr + offsets, mask=mask)
 y = tl.load(y_ptr + offsets, mask=mask)

 # Compute and store the result
 output = x + y
 tl.store(output_ptr + offsets, output, mask=mask)

def vector_add(x: torch.Tensor, y: torch.Tensor) -> torch.Tensor:
 """Launch the Triton vector addition kernel."""
 output = torch.empty_like(x)
 n_elements = output.numel()
 BLOCK_SIZE = 1024

 # Grid: number of blocks needed to cover all elements
 grid = lambda meta: (triton.cdiv(n_elements, meta["BLOCK_SIZE"]),)
 vector_add_kernel[grid](x, y, output, n_elements, BLOCK_SIZE=BLOCK_SIZE)
 return output

# Test
x = torch.randn(100_000, device="cuda", dtype=torch.float16)
y = torch.randn(100_000, device="cuda", dtype=torch.float16)
result = vector_add(x, y)
assert torch.allclose(result, x + y, atol=1e-3)
print("Triton vector addition: correct!")

2.2 Fused Softmax Kernel

Softmax is one of the most common operations in LLM inference, applied at every attention layer. A naive PyTorch implementation performs three separate passes over the data: compute the maximum (for numerical stability), compute exponentials, and normalize by the sum. Each pass reads and writes the entire tensor to HBM. A fused Triton kernel performs all three passes in a single kernel launch, keeping intermediate results in registers and SRAM.

# Fused softmax in Triton: three passes fused into one kernel launch
# Eliminates two round-trips to HBM compared to PyTorch's unfused version

import torch
import triton
import triton.language as tl

@triton.jit
def fused_softmax_kernel(
 input_ptr, output_ptr,
 n_cols,
 input_row_stride,
 output_row_stride,
 BLOCK_SIZE: tl.constexpr,
):
 # Each program handles one row of the input matrix
 row_idx = tl.program_id(0)
 row_start = row_idx * input_row_stride

 # Load one row into registers (fast on-chip memory)
 col_offsets = tl.arange(0, BLOCK_SIZE)
 mask = col_offsets < n_cols
 row = tl.load(input_ptr + row_start + col_offsets, mask=mask, other=-float("inf"))

 # Pass 1: find maximum for numerical stability (in registers)
 row_max = tl.max(row, axis=0)

 # Pass 2: compute exponentials (still in registers)
 numerator = tl.exp(row - row_max)

 # Pass 3: normalize (still in registers)
 denominator = tl.sum(numerator, axis=0)
 softmax_output = numerator / denominator

 # Single write to HBM (vs. 3 writes in unfused version)
 out_start = row_idx * output_row_stride
 tl.store(output_ptr + out_start + col_offsets, softmax_output, mask=mask)

def fused_softmax(x: torch.Tensor) -> torch.Tensor:
 """Fused softmax along the last dimension."""
 n_rows, n_cols = x.shape
 BLOCK_SIZE = triton.next_power_of_2(n_cols)
 output = torch.empty_like(x)

 fused_softmax_kernel[(n_rows,)](
 x, output,
 n_cols,
 x.stride(0), output.stride(0),
 BLOCK_SIZE=BLOCK_SIZE,
 )
 return output

# Benchmark against PyTorch
x = torch.randn(4096, 4096, device="cuda", dtype=torch.float16)
torch_result = torch.softmax(x, dim=-1)
triton_result = fused_softmax(x)
assert torch.allclose(triton_result, torch_result, atol=1e-2)
print("Fused softmax: correct! (3 memory passes reduced to 1)")

3. FlashAttention: Tiled Attention in SRAM

FlashAttention (Dao et al., 2022) is the most impactful custom kernel in the LLM ecosystem. The core insight is that the standard attention computation, $\text{softmax}(QK^T / \sqrt{d_k})V$, creates an $N \times N$ attention matrix (where $N$ is the sequence length) that must be materialized in HBM. For $N = 8192$ and FP16, this matrix is 128 MB per attention head. FlashAttention avoids materializing this matrix entirely by tiling the computation into blocks that fit in SRAM.

The algorithm processes the attention computation in tiles. For each tile of Q (a block of query rows), it iterates over all tiles of K and V, accumulating partial results in SRAM. The running softmax normalization is maintained using the "online softmax" trick: as each new block of K is processed, the running maximum and sum statistics are updated, and previous partial results are rescaled. This ensures numerical correctness without ever materializing the full attention matrix.

FlashAttention's memory complexity is $O(N)$ instead of $O(N^2)$, enabling much longer sequence lengths. FlashAttention-2 further improved throughput by 2x through better work partitioning across GPU warps, and FlashAttention-3 (for Hopper GPUs) exploits hardware-level asynchronous operations for another 1.5x improvement.

4. JIT Compilation: torch.compile and XLA

Not every optimization requires hand-written kernels. torch.compile (introduced in PyTorch 2.0) uses the TorchInductor backend to automatically fuse operations and generate optimized Triton kernels. For many workloads, simply wrapping your model in torch.compile captures 50% to 80% of the speedup that a hand-written kernel would provide, with zero additional code.

XLA (Accelerated Linear Algebra), the compiler backend for JAX and TensorFlow, takes a different approach: it compiles entire computation graphs into optimized code for the target hardware. XLA performs operator fusion, layout optimization, and memory planning at the graph level, often producing code competitive with hand-written kernels for standard operations.

The decision tree for optimization is: (1) try torch.compile first; (2) if that is insufficient, profile to identify the bottleneck; (3) write a custom Triton kernel only for the specific bottleneck operation. Hand-written kernels should be a last resort, not a first instinct.

# torch.compile: automatic kernel fusion without writing custom kernels

import torch
import torch.nn as nn
import time

class TransformerBlock(nn.Module):
 """A simplified transformer block for benchmarking."""
 def __init__(self, d_model=1024, n_heads=16):
 super().__init__()
 self.attn = nn.MultiheadAttention(d_model, n_heads, batch_first=True)
 self.norm1 = nn.LayerNorm(d_model)
 self.norm2 = nn.LayerNorm(d_model)
 self.ffn = nn.Sequential(
 nn.Linear(d_model, 4 * d_model),
 nn.GELU(),
 nn.Linear(4 * d_model, d_model),
 )

 def forward(self, x):
 # Pre-norm architecture
 h = self.norm1(x)
 h, _ = self.attn(h, h, h)
 x = x + h
 x = x + self.ffn(self.norm2(x))
 return x

device = torch.device("cuda")
model = TransformerBlock().to(device).half()
x = torch.randn(8, 512, 1024, device=device, dtype=torch.float16)

# Eager mode baseline
with torch.no_grad():
 for _ in range(10): # warmup
 _ = model(x)
 torch.cuda.synchronize()
 t0 = time.perf_counter()
 for _ in range(100):
 _ = model(x)
 torch.cuda.synchronize()
 eager_time = (time.perf_counter() - t0) / 100

# Compiled mode: torch.compile auto-fuses operations
compiled_model = torch.compile(model, mode="reduce-overhead")
with torch.no_grad():
 for _ in range(10): # warmup (includes compilation)
 _ = compiled_model(x)
 torch.cuda.synchronize()
 t0 = time.perf_counter()
 for _ in range(100):
 _ = compiled_model(x)
 torch.cuda.synchronize()
 compiled_time = (time.perf_counter() - t0) / 100

speedup = eager_time / compiled_time
print(f"Eager: {eager_time*1000:.2f} ms")
print(f"Compiled: {compiled_time*1000:.2f} ms")
print(f"Speedup: {speedup:.2f}x")

5. Performance Profiling

Effective GPU optimization requires precise measurement. The PyTorch profiler, NVIDIA Nsight Systems, and NVIDIA Nsight Compute provide complementary views: the PyTorch profiler shows operation-level timing within the Python framework; Nsight Systems shows the full timeline of CPU and GPU activity including kernel launches and memory transfers; Nsight Compute provides detailed per-kernel metrics including occupancy, memory throughput, and compute utilization.

The most common profiling mistake is measuring wall-clock time without GPU synchronization. GPU operations are asynchronous: when Python calls torch.matmul(A, B), the function returns immediately while the GPU works in the background. Without an explicit torch.cuda.synchronize() before timing measurements, you measure only the CPU-side overhead of launching the kernel, not the actual GPU execution time.

# PyTorch profiler: identifying kernel-level bottlenecks

import torch
from torch.profiler import profile, ProfilerActivity, schedule

model = torch.nn.TransformerEncoderLayer(
 d_model=1024, nhead=16, batch_first=True
).cuda().half()

x = torch.randn(8, 512, 1024, device="cuda", dtype=torch.float16)

# Profile with GPU activity tracking
with profile(
 activities=[ProfilerActivity.CPU, ProfilerActivity.CUDA],
 record_shapes=True,
 profile_memory=True,
 with_stack=True,
) as prof:
 with torch.no_grad():
 for _ in range(5):
 _ = model(x)
 torch.cuda.synchronize()

# Print the top 20 operations by GPU time
print(prof.key_averages().table(
 sort_by="cuda_time_total",
 row_limit=20,
 top_level_events_only=False,
))

# Export Chrome trace for visual inspection
# Open chrome://tracing and load this file
prof.export_chrome_trace("transformer_trace.json")
print("Trace exported to transformer_trace.json")
print("Open chrome://tracing in Chrome to visualize")

6. Putting It Together: Optimization Workflow

A systematic approach to LLM kernel optimization follows these steps:

1. Profile first. Use the PyTorch profiler to identify which operations consume the most GPU time. Focus on operations that appear repeatedly (attention, normalization, activation functions).
2. Classify the bottleneck. Use arithmetic intensity analysis (Code Fragment 9.7.1) to determine whether each bottleneck is memory-bound or compute-bound. Memory-bound operations benefit from fusion; compute-bound operations benefit from algorithmic improvements or hardware upgrades.
3. Try torch.compile. Apply torch.compile and re-profile. If the bottleneck is resolved, stop here. Check the generated Triton code to understand what the compiler did.
4. Write a targeted kernel. If torch.compile does not adequately fuse the bottleneck operation, write a custom Triton kernel for that specific operation. Start with correctness (compare against PyTorch reference), then optimize for performance.
5. Validate at scale. Test the optimized kernel at production-scale batch sizes and sequence lengths. Performance characteristics can change significantly between small test inputs and real workloads.

pip install transformers torch accelerate bitsandbytes

import torch
import time
from transformers import AutoModelForCausalLM, AutoTokenizer

model_name = "HuggingFaceTB/SmolLM2-360M-Instruct"
tokenizer = AutoTokenizer.from_pretrained(model_name)

# Baseline: FP16
torch.cuda.reset_peak_memory_stats()
model_fp16 = AutoModelForCausalLM.from_pretrained(
 model_name, torch_dtype=torch.float16, device_map="auto"
)
mem_fp16 = torch.cuda.max_memory_allocated() / 1024**2

prompt = "Explain the difference between compiled and interpreted languages."
inputs = tokenizer(prompt, return_tensors="pt").to(model_fp16.device)

# Warm-up run
with torch.no_grad():
 model_fp16.generate(**inputs, max_new_tokens=100)

# Timed run
start = time.perf_counter()
with torch.no_grad():
 out_fp16 = model_fp16.generate(**inputs, max_new_tokens=100)
latency_fp16 = time.perf_counter() - start

text_fp16 = tokenizer.decode(out_fp16[0], skip_special_tokens=True)
print(f"FP16 Memory: {mem_fp16:.0f} MB")
print(f"FP16 Latency: {latency_fp16:.3f}s")
print(f"FP16 Output: {text_fp16[:300]}")

from transformers import BitsAndBytesConfig

del model_fp16
torch.cuda.empty_cache()
torch.cuda.reset_peak_memory_stats()

# INT8 quantization
bnb_config = BitsAndBytesConfig(load_in_8bit=True)
model_int8 = AutoModelForCausalLM.from_pretrained(
 model_name, quantization_config=bnb_config, device_map="auto"
)
mem_int8 = torch.cuda.max_memory_allocated() / 1024**2

inputs = tokenizer(prompt, return_tensors="pt").to(model_int8.device)

# Warm-up and timed run
with torch.no_grad():
 model_int8.generate(**inputs, max_new_tokens=100)

start = time.perf_counter()
with torch.no_grad():
 out_int8 = model_int8.generate(**inputs, max_new_tokens=100)
latency_int8 = time.perf_counter() - start

text_int8 = tokenizer.decode(out_int8[0], skip_special_tokens=True)
print(f"\nINT8 Memory: {mem_int8:.0f} MB")
print(f"INT8 Latency: {latency_int8:.3f}s")
print(f"INT8 Output: {text_int8[:300]}")

import pandas as pd

results = pd.DataFrame([
 {"Precision": "FP16", "Memory (MB)": f"{mem_fp16:.0f}",
 "Latency (s)": f"{latency_fp16:.3f}",
 "Tokens": len(out_fp16[0])},
 {"Precision": "INT8", "Memory (MB)": f"{mem_int8:.0f}",
 "Latency (s)": f"{latency_int8:.3f}",
 "Tokens": len(out_int8[0])},
])
print("\n=== Quantization Comparison ===")
print(results.to_string(index=False))

savings = (1 - mem_int8 / mem_fp16) * 100
print(f"\nMemory savings: {savings:.1f}%")
print(f"\nFP16 snippet: {text_fp16[len(prompt):len(prompt)+200]}")
print(f"INT8 snippet: {text_int8[len(prompt):len(prompt)+200]}")
