Debugging Recipes

Deep learning code fails in characteristic ways. Tensors have the wrong shape. Gradients turn into NaN. Training runs OOM at unexpected moments. Models give different results on every run despite a fixed seed. This section catalogs the five most common categories of PyTorch failures, the diagnostics that localize each, and the patterns that resolve them. The goal is to turn cryptic stack traces into a small number of well-rehearsed playbooks.

Recipe: Hunting NaN and Inf

A NaN in the loss is the most demoralizing failure mode because it propagates instantly: one NaN in a forward pass becomes NaN logits, NaN loss, NaN gradients, and NaN parameters. The next iteration's forward pass produces all NaNs from those parameters, and recovery is impossible. The fix is to localize the source.

Step 1: Confirm it is happening. Insert assert torch.isfinite(loss).all() after the loss computation and assert all(torch.isfinite(p.grad).all() for p in model.parameters() if p.grad is not None) after backward. The earliest assertion that fires identifies which side of the optimizer the NaN appeared on.

Step 2: Localize within the forward pass. Register forward hooks (Section E.2) on every layer that record output.isfinite().all(). The first layer to produce a non-finite output is the culprit.

Step 3: Use anomaly detection for the backward pass. Wrap the training step in with torch.autograd.detect_anomaly(): and the framework will record forward-pass stack traces and replay them whenever a non-finite gradient is produced, identifying the precise operation. The overhead is large; use only during debugging.

import torch

def attach_nan_hooks(model):
    """Print the first layer whose forward output contains NaN/Inf."""
    def make_hook(name):
        def hook(module, inputs, output):
            t = output if torch.is_tensor(output) else output[0]
            if not torch.isfinite(t).all():
                bad = (~torch.isfinite(t)).sum().item()
                raise RuntimeError(
                    f"Non-finite values in `{name}`: {bad} entries, "
                    f"min={t.min()}, max={t.max()}"
                )
        return hook
    handles = []
    for name, module in model.named_modules():
        if len(list(module.children())) == 0:        # leaf modules only
            handles.append(module.register_forward_hook(make_hook(name)))
    return handles

handles = attach_nan_hooks(model)
try:
    loss = compute_loss(model(features), labels)   # raises if NaN appears
finally:
    for h in handles:
        h.remove()

The most common root causes of NaN in transformers are: a learning rate too high (especially without warmup; cosine into 0 is safer than linear into 0), missing gradient clipping (a single large batch can push gradients to infinity), softmax over very large logits (FP16 overflow; switch to bfloat16 or scale the inputs), a log over zero (numerical guard with x + epsilon), and a square root over a negative number (also a numerical guard).

Recipe: Diagnosing OOM

OOM means "tried to allocate more GPU memory than is free." The diagnostic question is: what is using the memory? The order of investigation is: (1) confirm batch size and sequence length; (2) check whether the OOM is on the first iteration (sizing problem) or later (leak); (3) capture a memory snapshot (Section E.8) and visualize it.

Once the culprit is identified, the standard mitigations are: lower batch size and use gradient accumulation to keep the effective batch size; enable activation checkpointing (significant memory reduction at the cost of an extra forward per backward); switch optimizer to a low-memory variant (bitsandbytes.optim.AdamW8bit stores Adam's momentum in 8-bit); shard the model with FSDP (Section E.7); offload to CPU memory with torch.cuda.amp.GradScaler or DeepSpeed's CPU-offload back end; reduce sequence length or pad to bucket boundaries.

Recipe: Shape Mismatches

Shape errors are the most common runtime failures. The error message reports the expected and actual shapes; the trick is to find where each shape came from. The fastest tool is to print the shape of every tensor at every layer boundary; print statements are crude but unbeatably fast for shape debugging.

A more durable approach is to annotate tensor shapes with named dimensions in comments (or with the einops library, which makes the convention machine-checked). The pattern # x: (B, L, D) alongside every tensor declaration trains the eye to spot mismatches at code-review time. For more advanced static-shape checking, the torchtyping library lets shape constraints be expressed in type annotations and verified at runtime.

import torch
from einops import rearrange

# Bad: a chain of reshape/transpose that is hard to read.
x = x.view(B, L, H, D).transpose(1, 2).reshape(B * H, L, D)

# Good: einops makes the rearrangement explicit and self-documenting.
x = rearrange(x, "b l (h d) -> (b h) l d", h=H)

# Even better: assert what you expect.
assert x.shape == (B * H, L, D), f"Got {x.shape}, expected {(B * H, L, D)}"

Recipe: Common Autograd Errors

Two autograd-related errors dominate beginner experience and a third is less common but harder to fix.

RuntimeError: leaf variable that requires grad has been used in an in-place operation

Some code mutated a parameter (or a tensor with requires_grad=True) in place. The fix is to use the out-of-place variant or, if mutation is intentional (optimizer step), wrap the mutation in with torch.no_grad():. Optimizer implementations use this pattern; user code rarely needs it.

RuntimeError: one of the variables needed for gradient computation has been modified by an inplace operation

An intermediate tensor that backward needs was overwritten by an in-place op (typically a += or .relu_()). The fix is to switch to out-of-place; the slight memory increase is far better than a broken backward pass. Use anomaly detection to identify the exact operation if the trace is not obvious.

RuntimeError: Trying to backward through the graph a second time

A second backward call on the same loss without retain_graph=True. Either intentional (in which case pass retain_graph=True) or unintentional (a stale graph reference, often from a hook closure holding the output). Investigate which one applies before adding retain_graph reflexively; the latter usually indicates a memory leak.

from torchinfo import summary

summary(model, input_size=(4, 3, 224, 224),
        col_names=["input_size", "output_size", "num_params"])

Recipe: Reproducibility

"Run the same code twice, get the same numbers" is harder than it looks. PyTorch has at least four independent sources of randomness: Python's random, NumPy's random, PyTorch's CPU generator, and PyTorch's CUDA generator(s), one per device. Several CUDA kernels also use non-deterministic algorithms by default. The full reproducibility recipe is therefore a small ritual.

import os, random, numpy as np, torch

def set_reproducible(seed=42):
    os.environ["PYTHONHASHSEED"] = str(seed)
    random.seed(seed)
    np.random.seed(seed)
    torch.manual_seed(seed)
    torch.cuda.manual_seed_all(seed)
    # cuDNN: pick deterministic algorithms.
    torch.backends.cudnn.deterministic = True
    torch.backends.cudnn.benchmark = False
    # PyTorch: error if a non-deterministic op is required.
    torch.use_deterministic_algorithms(True, warn_only=True)
    # Some ops need a CUBLAS workspace config for determinism.
    os.environ["CUBLAS_WORKSPACE_CONFIG"] = ":4096:8"

set_reproducible(42)

General Debugging Discipline

A handful of habits pay back many times over.

1. Overfit a single batch. A correctly implemented model should be able to drive the loss to near zero on a single repeated batch within a hundred steps. If it cannot, the bug is in the model or the optimizer, not the data or the training loop.
2. Train on a tiny subset before scaling. Reducing the dataset to 100 samples lets a full training run complete in seconds; many bugs (wrong loss, wrong target shape, label miscoding) reveal themselves immediately.
3. Log the gradient norm. A norm that rises without bound is divergence in progress; a norm that collapses to near zero is a model that has stopped learning. Both deserve investigation before training continues for hours.
4. Save a checkpoint at step zero. If a debugging session reveals the bug is in the model construction, the step-zero checkpoint is the ground truth to compare against.
5. Read the error message twice. PyTorch's error messages are often unusually informative (especially shape mismatches and CUDA errors); a careful read is faster than reaching for the debugger.
