Part V: Retrieval and Conversation
Chapter 20: Retrieval-Augmented Generation

Deep Research & Agentic RAG

The best researchers do not simply search once. They search, reflect, refine, and search again until the full picture emerges.

RAG RAG, Relentlessly Curious AI Agent
Big Picture

Naive RAG performs a single retrieval step, but complex research questions require multiple rounds of searching, reading, reflecting, and refining. Agentic RAG systems give the LLM the ability to decide what to search for, evaluate whether retrieved results are sufficient, generate follow-up queries, and synthesize findings from multiple sources. Building on the advanced retrieval techniques from Section 20.2, this transforms RAG from a simple retrieve-and-generate pattern into an autonomous research workflow that can tackle multi-faceted questions requiring information from diverse sources: document stores, web search, databases, and APIs.

Prerequisites

Agentic RAG combines the retrieval techniques from Section 20.1 and Section 20.2 with the agent design patterns that will be explored in depth in Chapter 22. You should understand basic prompt engineering from Section 11.1, as the agent loop relies on well-structured prompts to decide when and how to retrieve information.

A detective at a research desk surrounded by books and documents, following a looping process of searching, reading, thinking with question marks, and refining queries toward a glowing lightbulb
Figure 20.4.1: Agentic RAG iterates through search, evaluation, and refinement cycles until the full picture emerges.

1. From Single-Shot to Iterative Retrieval

Consider the research question: "How do the climate policies of the top 5 GDP countries compare in their approach to carbon taxation, and what evidence exists for the effectiveness of each approach?" This question cannot be answered with a single retrieval step. It requires identifying the top 5 GDP countries, finding each country's climate policy, extracting carbon taxation details, finding effectiveness studies for each approach, and then synthesizing the comparison.

Agentic RAG addresses this by giving the LLM a loop: plan what information is needed, retrieve it, evaluate whether it is sufficient, and either proceed to synthesis or generate follow-up queries. This iterative approach mirrors how a human researcher would tackle such a question, and it directly applies the agentic design patterns covered in Chapter 22.

Fun Fact

Agentic RAG systems can sometimes spiral into what practitioners call "research rabbit holes," where the agent keeps generating follow-up queries that get progressively further from the original question. Setting a maximum iteration count is less about compute cost and more about preventing your AI from writing a dissertation when you asked for a paragraph.

1.1 Query Decomposition

Key Insight

Query decomposition is where agentic RAG diverges most sharply from traditional RAG. In naive RAG, the user's question goes directly to the retriever. In agentic RAG, the LLM first plans the research strategy, much like a librarian who reads your question, thinks about which sections of the library to visit, and decides the order of lookups before pulling a single book off the shelf.

The first step in agentic RAG is decomposing a complex query into smaller, answerable sub-queries. Each sub-query targets a specific piece of information needed to construct the final answer. The decomposition can be sequential (each sub-query depends on the previous answer) or parallel (sub-queries are independent and can be executed concurrently). Figure 20.4.2 illustrates the agentic RAG loop from decomposition through synthesis. Code Fragment 20.4.1 below puts this into practice.

# implement decompose_query
# Key operations: evaluation logic, API interaction

from openai import OpenAI
import json
import asyncio

client = OpenAI()

def decompose_query(query):
 """Break a complex question into sub-queries."""
 response = client.chat.completions.create(
 model="gpt-4o",
 messages=[{
 "role": "system",
 "content": """Decompose the user's research question into
sub-queries. Return JSON with:
- "sub_queries": list of specific, searchable questions
- "dependencies": dict mapping query index to indices
 it depends on (empty list if independent)
- "strategy": "parallel" or "sequential"

Keep sub-queries focused and searchable."""
 }, {
 "role": "user",
 "content": query
 }],
 response_format={"type": "json_object"}
 )
 return json.loads(response.choices[0].message.content)

# Example usage
plan = decompose_query(
 "How do carbon tax policies in the EU and US compare, "
 "and what evidence exists for their effectiveness?"
)
# Returns sub-queries like:
# 1. "What are the current carbon tax policies in the EU?"
# 2. "What are the current carbon tax policies in the US?"
# 3. "What studies evaluate EU carbon tax effectiveness?"
# 4. "What studies evaluate US carbon pricing effectiveness?"
Code Fragment 20.4.1: The decompose_query function implements 1.1 query decomposition with async execution for concurrent processing.
Complex Query 1. Decompose Break into sub-queries 2. Search & Retrieve Web, docs, DB, APIs 3. Evaluate Sufficient? Credible? Insufficient: refine query Sufficient 4. Synthesize Combine + cite sources Research Report Web Docs DB
Figure 20.4.2: Agentic RAG iterates through decomposition, multi-source retrieval, and sufficiency evaluation before synthesizing a final answer.

2. Parallel Search and Multi-Source Retrieval

Once sub-queries are generated, an agentic RAG system can execute searches in parallel across multiple sources. Unlike naive RAG, which searches a single vector store, agentic RAG can simultaneously query document stores, web search APIs, databases, and specialized APIs, then combine results from all sources. Code Fragment 20.4.2 below puts this into practice.

# Implementation example
# See inline comments for step-by-step details.

import asyncio
from typing import List, Dict

async def search_web(query: str) -> List[Dict]:
 """Search the web using a search API."""
 # Implementation with Tavily, Serper, or Brave Search
 pass

async def search_documents(query: str, collection) -> List[Dict]:
 """Search internal document store."""
 results = collection.query(query_texts=[query], n_results=5)
 return [{"text": d, "source": "internal_docs"}
 for d in results["documents"][0]]

async def search_database(query: str) -> List[Dict]:
 """Convert query to SQL and search database."""
 # Text-to-SQL pipeline (covered in Section 20.5)
 pass

async def multi_source_search(sub_queries: List[str], collection):
 """Execute sub-queries in parallel across sources."""
 all_results = {}

 async def search_one(query):
 # Search all sources in parallel for each query
 web, docs, db = await asyncio.gather(
 search_web(query),
 search_documents(query, collection),
 search_database(query),
 return_exceptions=True
 )
 return {
 "query": query,
 "web": web if not isinstance(web, Exception) else [],
 "docs": docs if not isinstance(docs, Exception) else [],
 "db": db if not isinstance(db, Exception) else []
 }

 # Execute all sub-queries in parallel
 tasks = [search_one(q) for q in sub_queries]
 results = await asyncio.gather(*tasks)
 return results
Code Fragment 20.4.2: Connecting the agentic RAG loop to live web search APIs (Tavily, Serper, or Brave Search) to retrieve up-to-date information.

3. Iterative Refinement and Follow-Up Generation

After initial retrieval, the agent evaluates whether the gathered information is sufficient to answer the original question. If gaps remain, the agent generates follow-up queries targeting the missing information. This loop continues until the agent determines it has enough evidence or reaches a maximum iteration limit. Code Fragment 20.4.3 below puts this into practice.

# implement evaluate_and_refine
# Key operations: retrieval pipeline, evaluation logic, API interaction

def evaluate_and_refine(original_query, gathered_info, max_iterations=3):
 """Iteratively refine retrieval until sufficient."""

 for iteration in range(max_iterations):
 # Ask the LLM to evaluate sufficiency
 eval_response = client.chat.completions.create(
 model="gpt-4o",
 messages=[{
 "role": "system",
 "content": """Evaluate whether the gathered information is
sufficient to comprehensively answer the question.
Return JSON with:
- "sufficient": true/false
- "missing": list of what information is still needed
- "follow_up_queries": list of queries to fill gaps
- "confidence": 0.0 to 1.0"""
 }, {
 "role": "user",
 "content": f"""Original question: {original_query}

Gathered information:
{json.dumps(gathered_info, indent=2)}"""
 }],
 response_format={"type": "json_object"}
 )

 evaluation = json.loads(
 eval_response.choices[0].message.content
 )

 if evaluation["sufficient"] or evaluation["confidence"] > 0.85:
 return gathered_info, evaluation

 # Execute follow-up queries
 follow_ups = evaluation["follow_up_queries"]
 new_info = retrieve_for_queries(follow_ups)
 gathered_info.extend(new_info)

 return gathered_info, evaluation
Code Fragment 20.4.3: Running an iterative evaluate-and-refine loop where the LLM assesses whether gathered information is sufficient and generates follow-up queries if gaps remain.
Note

Production agentic RAG systems must balance thoroughness with cost and latency. Each iteration involves LLM calls for evaluation and follow-up generation, plus retrieval costs. Common budget strategies include: (1) a hard iteration cap (typically 3 to 5 rounds), (2) a total token budget across all iterations, (3) diminishing returns detection (stop when new iterations add little new information), and (4) time budgets for latency-sensitive applications.

4. Source Credibility Assessment

Not all retrieved sources are equally trustworthy. A critical feature of agentic RAG systems is the ability to assess source credibility and weight information accordingly. This is especially important when combining web search results (which may include misinformation) with curated internal documents. Figure 20.4.3 shows how credibility scores weight retrieved information before it reaches the LLM.

4.1 Credibility Signals

Peer-reviewed Gov / Official News articles Blog / Social Credibility Evaluator Authority, recency, consistency, bias Weighted Context High-trust first Low-trust flagged Conflicting noted LLM Generate
Figure 20.4.3: Source credibility assessment weights retrieved information by authority and reliability before passing it to the LLM.

5. Synthesis and Report Generation

The final stage of agentic RAG synthesizes all gathered information into a coherent, cited response. For complex research questions, this often means generating a structured report with sections, findings from multiple sources, points of agreement and disagreement, and explicit citations. Evaluating the quality of these synthesized reports requires the evaluation frameworks covered in Chapter 26. Code Fragment 20.4.4 below puts this into practice.

# implement synthesize_research
# Key operations: API interaction

def synthesize_research(original_query, gathered_info, credibility_scores):
 """Synthesize gathered information into a research report."""

 # Sort by credibility, place highest-trust sources first
 sorted_info = sorted(
 zip(gathered_info, credibility_scores),
 key=lambda x: x[1],
 reverse=True
 )

 context = "\n\n".join([
 f"[Source {i+1} | Credibility: {score:.1f}/5]\n{info['text']}"
 for i, (info, score) in enumerate(sorted_info)
 ])

 response = client.chat.completions.create(
 model="gpt-4o",
 messages=[{
 "role": "system",
 "content": """You are a research analyst. Synthesize the
provided sources into a comprehensive answer.

Guidelines:
- Cite sources by number [Source N]
- Note where sources agree or disagree
- Flag claims supported by only one source
- Prioritize high-credibility sources
- Acknowledge gaps in the evidence
- Structure the answer with clear sections"""
 }, {
 "role": "user",
 "content": f"""Research Question: {original_query}

Sources:
{context}"""
 }],
 temperature=0.2
 )

 return response.choices[0].message.content
Code Fragment 20.4.4: Synthesizing a research answer from multiple sources, weighting each by a credibility score and placing the most trustworthy evidence first.
Key Insight

The most effective synthesis prompts instruct the LLM to handle source disagreement explicitly rather than silently picking one version. When two high-credibility sources contradict each other, the system should present both perspectives with their supporting evidence and let the reader decide. This "epistemic honesty" approach builds far more user trust than confidently presenting a single answer that papers over genuine uncertainty.

6. Deep Research Architectures

Several production systems have implemented deep research capabilities that go well beyond simple agentic RAG. These systems typically combine query planning, multi-source retrieval, iterative refinement, and long-form synthesis into a unified workflow.

6.1 Architecture Comparison

6.1 Architecture Comparison
Feature Naive RAG Agentic RAG Deep Research
Retrieval steps 1 2 to 5 10+
Sources Single vector store Multiple stores Web + docs + DB + APIs
Query planning None Decomposition Hierarchical plan tree
Self-evaluation None Sufficiency check Multi-criteria assessment
Output format Short answer Cited answer Structured report
Typical latency 2 to 5 seconds 10 to 30 seconds 1 to 10 minutes
Cost per query $0.01 to $0.05 $0.05 to $0.50 $0.50 to $5.00
Warning

Agentic RAG introduces new failure modes beyond those of naive RAG. Query drift occurs when follow-up queries gradually shift away from the original question, retrieving increasingly irrelevant information. Infinite loops occur when the agent never reaches a "sufficient" evaluation. Conflation occurs when the agent mixes information from different sub-queries, creating false associations. Mitigate these with hard iteration limits, query relevance checks against the original question, and explicit source tracking throughout the pipeline. Figure 20.4.4 lays out the full deep research pipeline with its iterative phases.

Plan Query tree + source plan Gather Parallel search across N sources Verify Cross-check + credibility Refine Fill gaps via follow-up queries Synthesize Structured report with citations iterate until sufficient Typical execution: 1 to 10 minutes, 10 to 50 LLM calls, multiple source types
Figure 20.4.4: Deep research pipelines chain planning, gathering, verification, refinement, and synthesis into a multi-phase workflow with iteration.
Self-Check
Q1: Why does a complex research question require iterative retrieval rather than a single retrieval step?
Show Answer
Complex questions often require multiple pieces of information that cannot be captured by a single query. They may need sequential resolution (the answer to one sub-question is needed to formulate the next), information from different source types (web, documents, databases), and verification through cross-referencing. A single retrieval step would miss these dependencies and return incomplete or tangentially relevant results.
Q2: What is the difference between parallel and sequential query decomposition?
Show Answer
Parallel decomposition produces independent sub-queries that can all be executed simultaneously (e.g., "What is country A's policy?" and "What is country B's policy?"). Sequential decomposition produces dependent sub-queries where each depends on the answer to the previous one (e.g., "Who are the top 5 GDP countries?" must be answered before "What is each country's carbon tax rate?"). Many complex queries involve a mix of both patterns.
Q3: What credibility signals should an agentic RAG system consider when evaluating sources?
Show Answer
Five key credibility signals: (1) Source authority (recognized expertise in the domain), (2) Recency (newer information for time-sensitive topics), (3) Consistency (corroboration across multiple independent sources), (4) Specificity (concrete data and citations vs. vague claims), and (5) Bias indicators (commercial interests, political slant, or advocacy motivations that might skew the information).
Q4: What is query drift and how can it be mitigated in agentic RAG?
Show Answer
Query drift occurs when follow-up queries gradually shift away from the original question, retrieving increasingly irrelevant information with each iteration. It happens because follow-up queries are generated based on recent context rather than the original question. Mitigation strategies include: always comparing follow-up queries against the original question for relevance, including the original question in every refinement prompt, setting hard iteration limits, and implementing a relevance score that measures how related each new result is to the original query.
Q5: How should a synthesis prompt handle conflicting information from multiple sources?
Show Answer
Rather than silently picking one version, the synthesis should present both perspectives with their supporting evidence and source citations. It should note which sources agree and disagree, highlight claims supported by only one source versus multiple sources, prioritize high-credibility sources, and let the reader make the final judgment. This "epistemic honesty" approach builds more user trust than confidently presenting a single answer that hides genuine disagreement.
Tip: Use Hybrid Search (Vector + BM25)

Combine vector similarity with keyword search (BM25) using reciprocal rank fusion. Vector search catches semantic matches while BM25 catches exact terms, acronyms, and IDs that embedding models often miss. This hybrid approach typically improves recall by 10 to 20%.

Key Takeaways
Real-World Scenario: Building a Deep Research Agent for Competitive Intelligence

Who: A strategy analyst and an ML engineer at a venture capital firm

Situation: Analysts spent 8 to 12 hours per company compiling competitive landscape reports by manually searching SEC filings, news articles, patent databases, and industry publications.

Problem: A single RAG query could not answer complex questions like "How has Company X's AI strategy evolved over the past three years, and how does it compare to their top two competitors?" This required synthesizing dozens of sources across multiple time periods.

Dilemma: Running a fully autonomous agent with web search access risked runaway API costs (one early prototype spent $47 on a single query by iterating 80 times). Limiting iterations to 5 produced shallow, incomplete reports.

Decision: They built an agentic RAG system with a plan-then-execute architecture: the planner decomposed each research question into 5 to 8 sub-questions, each sub-question was answered independently with a 10-iteration budget, and a final synthesis step merged findings into a structured report.

How: Each sub-agent used adaptive retrieval (checking if existing context already answered the question before issuing new searches). A cost monitor enforced a $5 ceiling per report. The system used Tavily for web search and a local vector store for previously ingested documents.

Result: Report generation time dropped from 10 hours to 25 minutes. Analysts rated the automated reports as "comparable quality" to manual reports for 73% of queries. Average cost per report was $2.80.

Lesson: Deep research agents need explicit budgets (both iteration count and dollar cost), a plan-then-execute structure, and deduplication to avoid redundant searches. Unbounded iteration is the fastest path to wasted spend.

Library Shortcut: Agentic RAG with LlamaIndex

LlamaIndex (pip install llama-index) provides high-level abstractions for building agentic RAG systems. Its QueryEngineTool wraps retrieval pipelines as tools that an agent can invoke, and the ReActAgent handles the plan-retrieve-evaluate loop automatically.

# pip install llama-index llama-index-llms-openai
from llama_index.core import VectorStoreIndex, SimpleDirectoryReader
from llama_index.core.tools import QueryEngineTool, ToolMetadata
from llama_index.core.agent import ReActAgent
from llama_index.llms.openai import OpenAI

# Build indices over different document collections
sec_docs = SimpleDirectoryReader("./data/sec_filings").load_data()
news_docs = SimpleDirectoryReader("./data/news_articles").load_data()
sec_index = VectorStoreIndex.from_documents(sec_docs)
news_index = VectorStoreIndex.from_documents(news_docs)

# Wrap each index as a tool the agent can call
tools = [
 QueryEngineTool(
 query_engine=sec_index.as_query_engine(),
 metadata=ToolMetadata(
 name="sec_filings",
 description="Search SEC filings for financial data",
 ),
 ),
 QueryEngineTool(
 query_engine=news_index.as_query_engine(),
 metadata=ToolMetadata(
 name="news_search",
 description="Search recent news articles",
 ),
 ),
]

agent = ReActAgent.from_tools(tools, llm=OpenAI(model="gpt-4o"), verbose=True)
response = agent.chat("Compare NVIDIA's AI revenue growth to AMD's.")
Code Fragment 20.4.5: Building an agentic RAG system with LlamaIndex: two document collections (SEC filings and news) are wrapped as QueryEngineTools, and a ReActAgent orchestrates multi-source retrieval to answer complex comparative questions.
Research Frontier

Planning-based RAG agents decompose complex queries into retrieval plans before executing any searches, improving both efficiency (fewer unnecessary retrievals) and coverage (systematic exploration of the query space). Tool-augmented retrieval extends agentic RAG with access to calculators, code interpreters, and external APIs, enabling the agent to answer questions that require computation or real-time data. Multi-agent RAG assigns different retrieval strategies to specialized agents (one for dense search, one for structured queries, one for web search) that collaborate through a shared workspace. Research into retrieval agent safety is developing guardrails that prevent agents from executing harmful or privacy-violating queries.

Exercises

These exercises cover agentic RAG and deep research patterns.

Exercise 20.4.1: Single-shot vs. iterative Conceptual

Explain why a single retrieval step is insufficient for complex research questions. Give an example of a question that requires iterative retrieval.

Show Answer

Complex questions have information dependencies: the answer to one sub-question determines what to search next. Example: "How does Company X's revenue growth compare to its main competitors over the last 5 years?" requires first identifying competitors, then finding revenue data for each.

Exercise 20.4.2: Query drift Conceptual

Define query drift in the context of agentic RAG. How can you detect and prevent it?

Show Answer

Query drift occurs when follow-up queries gradually shift away from the original topic. Detect it by computing semantic similarity between each follow-up query and the original question. Prevent it by always including the original question as context when generating follow-up queries, and by setting a maximum drift threshold.

Exercise 20.4.3: Source credibility Coding

You are building a medical research agent. How would you implement source credibility assessment to prioritize peer-reviewed studies over blog posts?

Show Answer

Assign credibility scores based on: (a) source type (peer-reviewed journal > preprint > blog), (b) publication recency, (c) author credentials if available, (d) citation count. Use these scores as weights when assembling the context window, giving more space to higher-credibility sources.

Exercise 20.4.4: Sufficiency evaluation Conceptual

An agentic RAG system decides when it has "enough" information to answer. What criteria should this sufficiency check use? What happens if the threshold is too high or too low?

Show Answer

Criteria: all sub-questions answered, no contradictions between sources, information is recent enough, and key claims are supported by at least two independent sources. Too high: infinite loops, excessive API calls. Too low: incomplete or poorly supported answers.

Exercise 20.4.5: Deep research architecture Conceptual

Compare the deep research architectures of Gemini Deep Research and OpenAI's approach. What are the key phases, and how do they handle iteration?

Show Answer

Both follow a plan-search-synthesize loop. Gemini Deep Research emphasizes a visible research plan that users can review. Key phases: (1) plan generation, (2) iterative search and reading, (3) fact verification, (4) report synthesis. The iteration limit and breadth of search are the main differentiators.

Exercise 20.4.6: Iterative retrieval Coding

Implement a simple agentic RAG loop: (1) decompose a complex question into sub-questions, (2) retrieve for each sub-question, (3) evaluate if the combined information is sufficient, (4) generate follow-up queries if not.

Exercise 20.4.7: Multi-source search Coding

Build a parallel retrieval system that simultaneously queries a vector database, a web search API, and a knowledge graph. Implement result deduplication and source attribution.

Exercise 20.4.8: Source credibility scoring Coding

Implement a credibility assessment module that scores retrieved documents based on source domain, publication date, and citation count. Weight the scores in the final context assembly.

Exercise 20.4.9: Deep research agent Coding

Build a multi-phase deep research pipeline: planning phase (generate search plan), gathering phase (execute searches with iteration), verification phase (cross-check facts), and synthesis phase (generate a structured report with citations).

What Comes Next

In the next section, Section 20.5: Structured Data & Text-to-SQL, we cover structured data retrieval and text-to-SQL, enabling LLMs to query databases and structured sources.

References & Further Reading

Nakano, R. et al. (2021). "WebGPT: Browser-Assisted Question-Answering with Human Feedback." arXiv preprint.

One of the earliest demonstrations of an LLM that can browse the web and synthesize information. Laid the groundwork for agentic RAG systems. Foundational reading for deep research architectures.

Paper

Yao, S. et al. (2023). "ReAct: Synergizing Reasoning and Acting in Language Models." ICLR 2023.

Introduces the ReAct paradigm where models interleave reasoning traces with actions. The core pattern behind most agentic RAG systems. Essential reading for building iterative retrieval agents.

Paper

Shinn, N. et al. (2023). "Reflexion: Language Agents with Verbal Reinforcement Learning." NeurIPS 2023.

Proposes agents that learn from verbal self-reflection to improve over multiple attempts. Demonstrates how reflection loops enhance task performance. Valuable for designing self-correcting RAG pipelines.

Paper

Khattab, O. et al. (2023). "DSPy: Compiling Declarative Language Model Calls into Self-Improving Pipelines." arXiv preprint.

Introduces a programming framework for optimizing LLM pipelines, including multi-hop retrieval. Replaces manual prompt engineering with automated optimization. Recommended for advanced RAG pipeline builders.

Paper

Trivedi, H. et al. (2023). "Interleaving Retrieval with Chain-of-Thought Reasoning for Knowledge-Intensive Multi-Step Questions." ACL 2023.

Demonstrates that interleaving retrieval steps within chain-of-thought reasoning improves multi-hop question answering. A key technique for complex research queries. Useful for teams building deep research tools.

Paper

Tavily AI Search API.

A search API designed specifically for AI agents, providing structured web search results. Commonly used in agentic RAG frameworks for real-time information gathering. Practical tool for deep research implementations.

Tool
