Foundations of AI Agents

The best way to predict the future is to invent it. The second best way is to build an agent and let it figure things out.

Agent X, Self-Starting AI Agent

1. What Makes an Agent?

The term "agent" has been used loosely across the AI community, often applied to anything from a simple prompt chain to a fully autonomous system. To build effective agentic systems, we need precise definitions. An AI agent is a system that uses a language model to decide which actions to take and in what order, operating in a loop until a task is complete or a stopping condition is met. The critical distinction is autonomy in action selection: the model itself determines the next step rather than following a predetermined sequence.

The Perception-Reasoning-Action Loop

Every agent, regardless of its complexity, follows the same fundamental cycle. The agent perceives its environment by receiving input (user messages, tool outputs, observations from previous actions). It then reasons about what to do next using the language model. Finally, it takes an action, which could be calling a tool, generating a response, or requesting more information. The results of that action become new perceptions, and the cycle repeats. Figure 22.1.3 depicts this fundamental loop.

Agents vs. Chains vs. Workflows

Understanding the spectrum from simple to complex orchestration helps clarify where agents fit. The hybrid ML/LLM decision framework from Chapter 12 can help determine whether a full agent is necessary or a simpler pipeline suffices. A chain is a fixed sequence of LLM calls with predetermined steps. A workflow uses conditional logic (if/else, loops) but with control flow defined by the developer. An agent gives the LLM itself control over the execution path. The model decides which tools to call, in what order, and when to stop.

2. The Four Agentic Design Patterns

Andrew Ng identified four foundational agentic design patterns that appear across virtually all agent architectures. These patterns can be used individually or composed together, and understanding them provides a vocabulary for designing and analyzing agentic systems.

Pattern 1: Reflection

In the reflection pattern, the LLM reviews its own output and iteratively improves it. This can be as simple as asking the model to critique its response, or as sophisticated as having separate "generator" and "critic" roles. Reflection is powerful because it lets the model catch errors, improve quality, and refine its approach without external feedback. Code Fragment 22.1.2 below puts this into practice.

# implement reflect_and_improve
# Key operations: API interaction
import openai

client = openai.OpenAI()

def reflect_and_improve(task: str, max_rounds: int = 3) -> str:
 """Generate a response, then iteratively improve it via self-reflection."""

 # Step 1: Generate initial response
 draft = client.chat.completions.create(
 model="gpt-4o",
 messages=[{"role": "user", "content": task}]
 ).choices[0].message.content

 for round_num in range(max_rounds):
 # Step 2: Critique the current draft
 critique = client.chat.completions.create(
 model="gpt-4o",
 messages=[
 {"role": "system", "content": "You are a critical reviewer. Find flaws, "
 "gaps, and areas for improvement. Be specific."},
 {"role": "user", "content": f"Task: {task}\n\nDraft:\n{draft}\n\n"
 f"Provide specific, actionable critique."}
 ]
 ).choices[0].message.content

 # Step 3: Check if quality is satisfactory
 if "no major issues" in critique.lower():
 break

 # Step 4: Revise based on critique
 draft = client.chat.completions.create(
 model="gpt-4o",
 messages=[
 {"role": "system", "content": "Revise the draft to address all critique points."},
 {"role": "user", "content": f"Original task: {task}\n\n"
 f"Current draft:\n{draft}\n\n"
 f"Critique:\n{critique}\n\nRevised version:"}
 ]
 ).choices[0].message.content

 return draft

Pattern 2: Tool Use

Tool use extends the LLM beyond text generation by giving it the ability to call external functions: searching the web, querying databases, executing code, sending emails, or interacting with any API. The model receives tool descriptions, decides when and which tools to call, and incorporates the results into its reasoning. This is covered in depth in Section 22.2.

Tool use is architecturally significant, not merely an API feature. When a model gains the ability to call external functions, it transitions from a closed system (bounded by its training data) to an open system that can interact with the live world. This is the same leap that distinguishes a calculator from a spreadsheet connected to a database. The model's role shifts from "answer generator" to "action coordinator," and the design constraints change accordingly: latency now depends on external services, reliability depends on tool robustness, and safety requires controlling what actions the model can take. Chapter 23 explores these architectural implications in depth, including standardized protocols like MCP and A2A that formalize tool interfaces.

Pattern 3: Planning

Planning involves the LLM decomposing a complex task into subtasks before executing them. Rather than acting step by step reactively, a planning agent creates an explicit plan, then executes each step while potentially revising the plan based on intermediate results. Plan-and-execute architectures, reflection loops, and tree search methods all fall under this pattern. Section 22.3 covers planning in detail.

Pattern 4: Multi-Agent Collaboration

In the multi-agent pattern, multiple LLM instances (each potentially with different system prompts, tools, or roles) collaborate to solve a problem. One agent might research while another writes; a supervisor agent might coordinate workers; or agents might debate to reach a consensus. Chapter 23 is dedicated entirely to multi-agent architectures. Figure 22.1.5 summarizes these four patterns.

3. The ReAct Framework

ReAct (Reasoning + Acting) is the most widely adopted agent architecture. We introduced ReAct as a prompting pattern in Section 11.2; here we build it into a full agent system with tool execution, state management, and error handling. Algorithm 1 formalizes the ReAct loop.

Input: user task T, tool set {tool_1, ..., tool_n}, LLM M, max steps S
Output: final answer or action result

1. Initialize context = [system_prompt, T]
2. for step = 1 to S:
 a. Thought: response = M(context)
 The LLM reasons about current state, what is known, what is needed
 b. if response contains FINAL_ANSWER:
 return extracted answer
 c. Action: parse tool_name and arguments from response
 d. Observation: result = execute(tool_name, arguments)
 e. Append (Thought, Action, Observation) to context
3. return "Max steps reached without resolution"


The key insight is that the explicit reasoning in step 2a (the "Thought") dramatically improves decision quality compared to acting without thinking or thinking without acting. Each thought provides a chain-of-reasoning that is also valuable for debugging when the agent makes mistakes.

# Define ReActAgent; implement __init__, run, _execute_action
# Key operations: agent orchestration, tool integration, prompt construction
from typing import Callable

class ReActAgent:
 """Minimal ReAct agent: Thought -> Action -> Observation loop."""

 def __init__(self, client, tools: dict[str, Callable], model: str = "gpt-4o"):
 self.client = client
 self.tools = tools
 self.model = model

 def run(self, task: str, max_steps: int = 10) -> str:
 # Build tool descriptions for the system prompt
 tool_desc = "\n".join(
 f"- {name}: {func.__doc__}" for name, func in self.tools.items()
 )

 system_prompt = f"""You are a ReAct agent. For each step:
1. Thought: Reason about the current state and what to do next
2. Action: Call a tool using the format: ACTION: tool_name(args)
3. Wait for Observation (tool result)

When you have the final answer, respond: FINAL ANSWER: [your answer]

Available tools:
{tool_desc}"""

 messages = [
 {"role": "system", "content": system_prompt},
 {"role": "user", "content": task}
 ]

 for step in range(max_steps):
 response = self.client.chat.completions.create(
 model=self.model,
 messages=messages
 ).choices[0].message.content

 messages.append({"role": "assistant", "content": response})

 # Check for final answer
 if "FINAL ANSWER:" in response:
 return response.split("FINAL ANSWER:")[1].strip()

 # Parse and execute action
 if "ACTION:" in response:
 action_str = response.split("ACTION:")[1].strip()
 observation = self._execute_action(action_str)
 messages.append({
 "role": "user",
 "content": f"Observation: {observation}"
 })

 return "Max steps reached without final answer."

 def _execute_action(self, action_str: str) -> str:
 # Parse "tool_name(args)" format and execute
 try:
 name = action_str.split("(")[0].strip()
 args_str = action_str.split("(", 1)[1].rsplit(")", 1)[0]
 if name in self.tools:
 return str(self.tools[name](args_str))
 return f"Error: Unknown tool '{name}'"
 except Exception as e:
 return f"Error executing action: {e}"

ReAct Trace Example

A typical ReAct trace shows the interleaved thought-action-observation pattern. Notice how the agent explicitly reasons before each action, and how observations feed back into the next reasoning step. Code Fragment 22.1.4 below puts this into practice.

# Example trace for: "What is the population of the capital of France?"

Thought: I need to find the capital of France, then look up its population.
 The capital of France is Paris, but let me verify and get the
 current population figure.

Action: search("Paris population 2024")

Observation: Paris has a city population of approximately 2.1 million
 and a metropolitan area population of about 12.3 million.

Thought: I now have the information. The capital of France is Paris,
 with a city population of about 2.1 million. I should provide
 both the city and metro figures for completeness.

FINAL ANSWER: The capital of France is Paris, with a city population
of approximately 2.1 million and a metropolitan area population
of about 12.3 million.

4. Cognitive Architectures and State Machines

As agents grow more complex, the simple ReAct loop becomes insufficient. Cognitive architectures provide a richer framework for organizing agent behavior by introducing explicit state management, memory systems, and structured decision-making processes. A cognitive architecture defines how an agent thinks, not just what it thinks about.

Agent State Machines

Many production agents are best modeled as state machines, where the agent transitions between well-defined states based on its observations and decisions. This provides predictability and debuggability while still allowing the LLM to make autonomous decisions within each state. Figure 22.1.6 shows the agent state machine with its transitions. Code Fragment 22.1.5 below puts this into practice.

# Define AgentState, AgentContext, StatefulAgent; implement __init__, run, _handle_planning
# Key operations: agent orchestration, tool integration, API interaction
from enum import Enum
from dataclasses import dataclass, field

class AgentState(Enum):
 PLANNING = "planning"
 EXECUTING = "executing"
 REFLECTING = "reflecting"
 WAITING_FOR_HUMAN = "waiting_for_human"
 COMPLETE = "complete"
 ERROR = "error"

@dataclass
class AgentContext:
 """Tracks the full state of an agent's execution."""
 task: str
 state: AgentState = AgentState.PLANNING
 plan: list[str] = field(default_factory=list)
 completed_steps: list[str] = field(default_factory=list)
 observations: list[dict] = field(default_factory=list)
 current_step_index: int = 0
 error_count: int = 0
 max_errors: int = 3

class StatefulAgent:
 """Agent that operates as a state machine with explicit transitions."""

 def __init__(self, client, tools):
 self.client = client
 self.tools = tools
 self.transitions = {
 AgentState.PLANNING: self._handle_planning,
 AgentState.EXECUTING: self._handle_executing,
 AgentState.REFLECTING: self._handle_reflecting,
 AgentState.ERROR: self._handle_error,
 }

 def run(self, task: str) -> str:
 ctx = AgentContext(task=task)

 while ctx.state not in (AgentState.COMPLETE, AgentState.WAITING_FOR_HUMAN):
 handler = self.transitions.get(ctx.state)
 if handler:
 ctx = handler(ctx)
 else:
 break

 return self._format_result(ctx)

 def _handle_planning(self, ctx: AgentContext) -> AgentContext:
 # LLM creates a step-by-step plan
 plan = self._call_llm(
 f"Break this task into concrete steps:\n{ctx.task}"
 )
 ctx.plan = self._parse_plan(plan)
 ctx.state = AgentState.EXECUTING
 return ctx

 def _handle_executing(self, ctx: AgentContext) -> AgentContext:
 if ctx.current_step_index >= len(ctx.plan):
 ctx.state = AgentState.REFLECTING
 return ctx

 step = ctx.plan[ctx.current_step_index]
 try:
 result = self._execute_step(step, ctx)
 ctx.observations.append({"step": step, "result": result})
 ctx.completed_steps.append(step)
 ctx.current_step_index += 1
 except Exception as e:
 ctx.error_count += 1
 ctx.state = AgentState.ERROR if ctx.error_count >= ctx.max_errors \
 else AgentState.EXECUTING
 return ctx

 def _handle_reflecting(self, ctx: AgentContext) -> AgentContext:
 # LLM reviews results and decides: complete or replan
 assessment = self._call_llm(
 f"Task: {ctx.task}\nCompleted: {ctx.completed_steps}\n"
 f"Results: {ctx.observations}\n\n"
 f"Is the task fully complete? If not, what remains?"
 )
 if "complete" in assessment.lower():
 ctx.state = AgentState.COMPLETE
 else:
 ctx.state = AgentState.PLANNING # Replan with new context
 return ctx

5. Agent Memory Systems

Effective agents require memory that goes beyond the conversation history within a single context window. Agent memory can be categorized into three types, each serving a different purpose and operating at a different timescale.

Working Memory (Short-Term)

Working memory holds the current conversation context, including the system prompt, user messages, tool calls and their results, and the agent's reasoning traces. This maps directly to the LLM's context window and is the most straightforward form of memory. The challenge is that it is bounded: as the agent takes more actions, the context window fills up.

Episodic Memory (Session-Based)

Episodic memory stores records of past interactions, allowing agents to recall previous conversations, successful strategies, and common user preferences. This is typically implemented via Chapter 19) or structured databases that the agent can query.

Semantic Memory (Long-Term Knowledge)

Semantic memory stores factual knowledge, learned procedures, and domain-specific information. This includes the agent's tool documentation, domain knowledge bases, and procedural memory about how to accomplish recurring tasks. RAG systems (Chapter 20) are the primary mechanism for semantic memory. Code Fragment 22.1.6 below puts this into practice.

# Define AgentMemory; implement add_to_working, save_episode, recall_relevant
# Key operations: retrieval pipeline, vector search, agent orchestration
from dataclasses import dataclass, field
from datetime import datetime

@dataclass
class AgentMemory:
 """Three-tier memory system for an AI agent."""

 # Working memory: current context window contents
 working: list[dict] = field(default_factory=list)
 max_working_tokens: int = 100_000

 # Episodic memory: past interaction summaries
 episodes: list[dict] = field(default_factory=list)

 # Semantic memory: learned facts and procedures
 knowledge: dict[str, str] = field(default_factory=dict)

 def add_to_working(self, message: dict):
 """Add a message to working memory, evicting old entries if needed."""
 self.working.append(message)
 self._evict_if_needed()

 def save_episode(self, summary: str, outcome: str):
 """Save a completed interaction to episodic memory."""
 self.episodes.append({
 "timestamp": datetime.now().isoformat(),
 "summary": summary,
 "outcome": outcome
 })

 def recall_relevant(self, query: str, top_k: int = 3) -> list[dict]:
 """Retrieve relevant episodes (in production, use vector similarity)."""
 # Simplified: in practice, embed query and search vector store
 return self.episodes[-top_k:]

 def _evict_if_needed(self):
 """Summarize and evict old messages when context is too large."""
 # Estimate token count (rough: 4 chars per token)
 total = sum(len(str(m)) // 4 for m in self.working)
 while total > self.max_working_tokens and len(self.working) > 2:
 # Summarize oldest messages and replace them
 removed = self.working.pop(1) # Keep system prompt at index 0
 self.save_episode(str(removed)[:200], "evicted")
 total = sum(len(str(m)) // 4 for m in self.working)

Reflexion: Learning from Failure Through Self-Reflection

The Reflexion framework (Shinn et al., 2023) extends the basic reflection pattern into a full learning architecture. While the simple reflection loop (generate, critique, revise) operates within a single task attempt, Reflexion operates across multiple attempts: the agent tries a task, evaluates its performance, generates a natural language reflection on what went wrong, stores that reflection in memory, and uses it to improve on subsequent attempts. This creates a form of "verbal reinforcement learning" where the reward signal is translated into natural language lessons.

Why does this matter? Standard agents repeat the same mistakes across sessions because they have no mechanism for learning from failure. A coding agent that hits a specific type of error will make the same mistake every time it encounters a similar problem. Reflexion gives agents an explicit learning loop: fail, reflect, remember, improve.

The Act / Evaluate / Reflect / Store Loop

Reflexion operates in four phases. In the Act phase, the agent attempts the task using its current approach plus any stored reflections from previous attempts. In the Evaluate phase, the agent (or an external evaluator) assesses whether the attempt succeeded, using task-specific criteria (test cases for code, factual accuracy for QA, goal completion for planning). In the Reflect phase, if the attempt failed, the agent generates a natural language analysis of what went wrong and what to try differently. In the Store phase, the reflection is saved to episodic memory and prepended to the prompt on the next attempt.

The results speak for themselves. On HumanEval (a coding benchmark), Reflexion achieved 91.0% accuracy, compared to 67.0% for standard GPT-4 and 80.1% for GPT-4 with simple retry. The gains come not from better base capabilities but from the agent's ability to learn from its own mistakes within a single problem-solving session. Each failed attempt provides specific, actionable feedback ("the function fails on edge case where input is an empty list") that directly improves the next attempt.

# Reflexion agent for code generation tasks
from openai import OpenAI
import subprocess
import sys

client = OpenAI()

class ReflexionAgent:
 """Agent that learns from failures through self-reflection."""

 def __init__(self, max_attempts: int = 4):
 self.max_attempts = max_attempts
 self.reflections: list[str] = []

 def solve(self, task: str, test_cases: str) -> str:
 """Attempt to solve a coding task, learning from failures."""

 for attempt in range(self.max_attempts):
 # ACT: Generate code with reflections as context
 reflection_context = ""
 if self.reflections:
 reflection_context = (
 "Lessons from previous attempts:\n"
 + "\n".join(f"- {r}" for r in self.reflections)
 + "\n\nUse these lessons to avoid repeating mistakes.\n\n"
 )

 code = client.chat.completions.create(
 model="gpt-4o",
 messages=[{
 "role": "user",
 "content": (
 f"{reflection_context}"
 f"Write a Python function to solve this task:\n{task}\n\n"
 f"Return only the function code."
 )
 }],
 temperature=0.2
 ).choices[0].message.content

 # EVALUATE: Run test cases
 success, output = self._run_tests(code, test_cases)

 if success:
 print(f"Solved on attempt {attempt + 1}!")
 return code

 # REFLECT: Generate a reflection on the failure
 reflection = client.chat.completions.create(
 model="gpt-4o",
 messages=[{
 "role": "user",
 "content": (
 f"My code for this task failed:\n"
 f"Task: {task}\n"
 f"Code: {code}\n"
 f"Error: {output}\n\n"
 f"In 1-2 sentences, explain what went wrong "
 f"and what specific change would fix it."
 )
 }],
 temperature=0
 ).choices[0].message.content

 # STORE: Save reflection for next attempt
 self.reflections.append(reflection)
 print(f"Attempt {attempt + 1} failed. Reflection: {reflection}")

 return "Failed after max attempts"

 def _run_tests(self, code: str, test_cases: str) -> tuple[bool, str]:
 """Execute code with test cases and return (success, output)."""
 full_code = f"{code}\n\n{test_cases}"
 try:
 result = subprocess.run(
 [sys.executable, "-c", full_code],
 capture_output=True, text=True, timeout=10
 )
 if result.returncode == 0:
 return True, result.stdout
 return False, result.stderr
 except subprocess.TimeoutExpired:
 return False, "Timeout: code took more than 10 seconds"

# Usage
agent = ReflexionAgent(max_attempts=4)
solution = agent.solve(
 task="Write a function 'flatten(lst)' that flattens arbitrarily nested lists.",
 test_cases="""
assert flatten([1, [2, 3], [4, [5, 6]]]) == [1, 2, 3, 4, 5, 6]
assert flatten([]) == []
assert flatten([[[[1]]]]) == [1]
assert flatten([1, 2, 3]) == [1, 2, 3]
print("All tests passed!")
"""
)

Graph-Based Agent Memory

Vector-based memory (Section 5 above) excels at finding semantically similar past experiences, but it struggles with a specific class of queries: those requiring relational reasoning across multiple pieces of information. If an agent remembers that "Alice manages the payments team" and "the payments team owns the billing microservice," a vector search for "who owns the billing microservice" might not surface the answer because neither memory directly mentions Alice in the context of the billing service. Graph-based memory solves this by storing information as knowledge graph triples (subject, predicate, object) and supporting multi-hop traversal.

Why does this matter for agents? Agents operating in complex environments accumulate knowledge about entities and their relationships: which tools are available for which tasks, which API endpoints serve which data, which team members have which expertise. Flat vector memory treats each piece of knowledge independently. Graph memory preserves the connections between entities, enabling the agent to answer questions that require combining multiple facts.

When Graph Memory Beats Vector Memory

Graph memory outperforms vector memory in three specific scenarios. First, multi-hop queries that require chaining two or more facts: "What is the timezone of the server that hosts the billing service?" requires looking up the server, then looking up its timezone. Second, relationship queries where the connection between entities matters: "Which teams does Alice collaborate with?" requires traversing relationship edges, not finding similar text. Third, consistency enforcement where adding a new fact should propagate updates: if "Alice moved to the infrastructure team," all downstream facts about Alice's team assignments should update. The knowledge graph RAG patterns in Section 20.5 provide additional context on graph-structured retrieval.

# Graph-based agent memory using triples
from dataclasses import dataclass, field
from typing import Optional

@dataclass
class Triple:
 """A knowledge graph triple: (subject, predicate, object)."""
 subject: str
 predicate: str
 object: str
 confidence: float = 1.0
 source: str = "" # which conversation produced this
 timestamp: float = 0.0

class GraphMemory:
 """Knowledge graph memory for agents with multi-hop query support."""

 def __init__(self):
 self.triples: list[Triple] = []
 self.entity_index: dict[str, list[int]] = {} # entity -> triple indices

 def add(self, subject: str, predicate: str, obj: str,
 confidence: float = 1.0, source: str = "") -> None:
 """Add a triple, updating if a conflicting triple exists."""
 import time

 # Check for conflicting triple (same subject + predicate)
 for i, t in enumerate(self.triples):
 if t.subject == subject and t.predicate == predicate:
 # Update with new information
 self.triples[i] = Triple(
 subject, predicate, obj,
 confidence, source, time.time()
 )
 return

 triple = Triple(subject, predicate, obj,
 confidence, source, time.time())
 idx = len(self.triples)
 self.triples.append(triple)

 # Index by both subject and object for traversal
 self.entity_index.setdefault(subject.lower(), []).append(idx)
 self.entity_index.setdefault(obj.lower(), []).append(idx)

 def query(self, subject: Optional[str] = None,
 predicate: Optional[str] = None,
 obj: Optional[str] = None) -> list[Triple]:
 """Find triples matching the given pattern (None = wildcard)."""
 results = []
 for t in self.triples:
 if subject and t.subject.lower() != subject.lower():
 continue
 if predicate and t.predicate.lower() != predicate.lower():
 continue
 if obj and t.object.lower() != obj.lower():
 continue
 results.append(t)
 return results

 def multi_hop(self, start_entity: str, hops: int = 2) -> dict:
 """Traverse the graph from an entity up to N hops."""
 visited = set()
 current_layer = {start_entity.lower()}
 all_facts = {}

 for hop in range(hops):
 next_layer = set()
 for entity in current_layer:
 if entity in visited:
 continue
 visited.add(entity)

 triples = self.query(subject=entity)
 triples += self.query(obj=entity)

 for t in triples:
 key = f"{t.subject} -> {t.predicate} -> {t.object}"
 all_facts[key] = t
 next_layer.add(t.subject.lower())
 next_layer.add(t.object.lower())

 current_layer = next_layer - visited

 return all_facts

# Usage: Agent builds knowledge graph from observations
graph = GraphMemory()

# Agent learns facts during tool use
graph.add("billing-service", "hosted_on", "us-east-prod-3")
graph.add("us-east-prod-3", "timezone", "America/New_York")
graph.add("Alice", "manages", "payments-team")
graph.add("payments-team", "owns", "billing-service")

# Multi-hop query: "What timezone is the billing service in?"
facts = graph.multi_hop("billing-service", hops=2)
for fact_key, triple in facts.items():
 print(f" {fact_key}")
# billing-service -> hosted_on -> us-east-prod-3
# us-east-prod-3 -> timezone -> America/New_York
# payments-team -> owns -> billing-service
# Alice -> manages -> payments-team

5b. Procedural Memory: Skill Libraries

The three-tier memory model (working, episodic, semantic) captures what happened and what the agent knows, but it misses a crucial dimension: how to do things. Procedural memory stores reusable tool-use patterns, multi-step recipes, and learned strategies that the agent can invoke when it encounters a familiar situation. While episodic memory records "I searched the database and found the answer in the users table," procedural memory records "when asked to find user data, first check the users table, then join with the profiles table for additional fields."

Episodic vs. Semantic vs. Procedural Memory

These three memory types serve distinct roles. Episodic memory stores specific experiences: what happened, when, and in what context. It answers questions like "What did I do last time the user asked about billing?" Semantic memory stores factual knowledge: entities, relationships, and general truths. It answers "What is the billing API endpoint?" Procedural memory stores skills: sequences of actions that achieve goals. It answers "How do I resolve a billing dispute?" The distinction matters because procedural knowledge generalizes across contexts in ways that episodic memory cannot. An agent with a "resolve billing dispute" skill can apply it to any customer, while an episodic memory of one specific dispute is harder to transfer.

Voyager: A Skill Library That Grows

The Voyager system (Wang et al., 2023) demonstrated procedural memory in the Minecraft game environment. Voyager's agent builds a skill library of reusable JavaScript functions, each representing a learned behavior (mine wood, build a shelter, craft a pickaxe). When the agent encounters a new task, it first searches the skill library for relevant existing skills before attempting to write new code. Successfully verified skills are added to the library, creating a growing repertoire of capabilities. The key insight is that skills compose: "build a house" can call "mine wood," "craft planks," and "place blocks" as subroutines. This compositional structure enables the agent to tackle increasingly complex tasks without relearning basic behaviors.

Skill Library Lookup in Practice

The following pseudocode illustrates the core pattern of a skill library that stores, retrieves, and composes procedural knowledge.

# Skill library: procedural memory for agents
from dataclasses import dataclass
from typing import Callable

@dataclass
class Skill:
 name: str
 description: str # natural language description for retrieval
 preconditions: list[str] # what must be true before execution
 code: str # the executable procedure
 success_count: int = 0 # reinforcement signal

class SkillLibrary:
 def __init__(self, embed_fn, threshold=0.75):
 self.skills: dict[str, Skill] = {}
 self.embed_fn = embed_fn
 self.threshold = threshold

 def add_skill(self, skill: Skill):
 """Store a verified skill in the library."""
 self.skills[skill.name] = skill

 def retrieve(self, task_description: str, top_k=3) -> list[Skill]:
 """Find skills relevant to the current task via embedding similarity."""
 task_emb = self.embed_fn(task_description)
 scored = []
 for skill in self.skills.values():
 sim = cosine_similarity(task_emb, self.embed_fn(skill.description))
 if sim >= self.threshold:
 scored.append((sim, skill))
 scored.sort(key=lambda x: -x[0])
 return [s for _, s in scored[:top_k]]

 def compose(self, skill_names: list[str]) -> str:
 """Chain multiple skills into a composite procedure."""
 steps = []
 for name in skill_names:
 if name in self.skills:
 steps.append(f"# Step: {name}\n{self.skills[name].code}")
 return "\n\n".join(steps)

# Usage: agent checks library before writing new code
relevant_skills = library.retrieve("gather wood and build a crafting table")
if relevant_skills:
 plan = library.compose([s.name for s in relevant_skills])
else:
 plan = llm_generate_new_skill(task_description)

6. Token Budget Management

Token management is one of the most practical challenges in building agents. Unlike a single-turn completion where you control the input size, agents accumulate context over many iterations. Without careful budgeting, agents hit context limits, lose important early context, or incur excessive costs.

Strategies for Managing Token Budgets

• Summarize tool outputs: Instead of including raw API responses, extract only the relevant fields. A search result page might be 10,000 tokens raw but only 200 tokens of useful information.
• Sliding window with summarization: Periodically summarize older conversation turns and replace them with a compact summary, keeping recent turns intact.
• Tiered context priority: Assign priorities to different message types. System prompts and the current task have highest priority; old tool results have lowest priority and are evicted first.
• Lazy loading: Instead of loading all context upfront, fetch information only when the agent needs it. Store tool descriptions in a separate index and inject only the ones the agent requests.
• Step limits: Set hard limits on the number of agent iterations. If the agent cannot solve a task in N steps, it should report what it found and ask for guidance.

7. Designing for Failure

Agents fail in ways that are qualitatively different from non-agentic systems. A simple chain either succeeds or produces an error. An agent can get stuck in loops, waste tokens on unproductive actions, misinterpret tool outputs, or take increasingly erratic actions as its context window degrades. Robust agent design requires anticipating and handling these failure modes. Chapter 29 covers how to observe and measure these failures in production.

Common Agent Failure Modes

• Infinite loops: The agent repeats the same action because it does not recognize that the result is unchanged. Always implement a maximum step counter.
• Tool misuse: The agent calls a tool with invalid arguments or misinterprets the output. Clear tool descriptions and structured error messages help.
• Goal drift: Over many steps, the agent gradually shifts away from the original task. Periodically re-injecting the original task description helps maintain focus.
• Context window overflow: The agent accumulates so much history that it cannot generate useful output. Token management strategies (above) are essential.
• Cascading errors: An early mistake propagates through subsequent steps, leading the agent further astray. Reflection checkpoints catch and correct errors early.

Exercises
