Research & Data Analysis Agents

"Data does not speak for itself. It needs an agent who can read, query, plot, and then explain what it all means."

Agent X, Methodically Analytical AI Agent

29.3.1 Deep Research Agents

Research agents automate the process of gathering, analyzing, and synthesizing information from multiple sources. Unlike simple RAG systems that retrieve and summarize, research agents plan their research strategy, execute multi-step information gathering, evaluate source quality, identify gaps in their findings, and produce comprehensive reports with citations. This mirrors how a human researcher works: formulate a question, search for sources, read and evaluate them, identify what is still missing, search again, and synthesize.

The plan-and-execute architecture from Section 29.2 is the natural fit for research agents. The planning phase generates a research outline with specific questions to answer. The execution phase uses search tools (web search, academic search, database queries) to find relevant sources for each question. A synthesis phase combines findings into a coherent report. A reflection phase identifies gaps and triggers additional research cycles. OpenAI's Deep Research and Gemini's Deep Research features implement this pattern at scale.

The Plan-Execute-Reflect Loop

The four phases just described are not a straight pipeline; they are a loop whose continuation depends on what the agent has found so far. The skeleton below makes the control flow explicit: a planner turns the question into a set of sub-questions, the executor retrieves and reads sources for each open sub-question and extracts claims, and a reflection step scores how much of the question is now covered and proposes new sub-questions for whatever remains. The loop repeats until coverage crosses a threshold or a budget (search calls or wall-clock) is exhausted, whichever comes first. The two stopping conditions are both necessary: coverage alone can loop forever on an unanswerable question, and a budget alone would stop a nearly-finished investigation one search short.

# Deep-research control loop: plan sub-questions, retrieve + read +
# extract per sub-question, then reflect to find gaps and replan.
# Stops when coverage clears a threshold or the search budget runs out.
def deep_research(
    question: str,
    coverage_target: float = 0.8,
    max_searches: int = 40,
) -> Report:
    open_questions = plan_subquestions(question)  # initial decomposition
    findings: list[Finding] = []
    searches_used = 0

    while open_questions and searches_used < max_searches:
        sq = open_questions.pop(0)
        sources = retrieve(sq)           # web/academic/db search tools
        searches_used += 1
        for src in sources:
            claims = read_and_extract(src, sq)  # claims grounded in src
            cred = credibility(src, findings)   # see scoring below
            findings.append(Finding(sq, src, claims, cred))

        # Reflect: how much of the question is covered, and what is missing?
        coverage, gaps = reflect(question, findings)
        if coverage >= coverage_target:
            break                            # enough evidence; stop early
        open_questions.extend(gaps)        # replan: chase the gaps

    return synthesize(question, findings)     # report with citations

Quality control is the critical differentiator between good and poor research agents. Effective research agents implement source credibility scoring (preferring academic papers over blog posts, primary sources over secondary ones), cross-reference verification (checking claims against multiple independent sources), recency filtering (prioritizing recent information for fast-moving topics), and explicit uncertainty flagging (noting when findings conflict or when evidence is limited).

Scoring Credibility and Gaps

The two scalars that drive the loop, the per-source credibility and the overall coverage, are easy to assert and harder to make mechanical. Making them concrete is what turns "the agent prefers reliable sources" from a slogan into a number the loop can act on. We score each source's credibility as a weighted sum of three signals: a source-type prior (a peer-reviewed paper or official documentation starts higher than a forum post), a recency term that decays with age (important for fast-moving topics, near-irrelevant for settled ones), and a corroboration count capturing how many independent already-collected sources assert the same claim. Writing p for the source-type prior, r for recency, and c for the corroboration count, all on a 0-to-1 scale:

credibility = 0.5 · p + 0.2 · r + 0.3 · min(c / 3, 1)

The weights say that what the source is matters most (0.5), corroboration matters next (0.3), and recency is a tie-breaker (0.2); the min(c / 3, 1) caps the corroboration bonus so that three independent confirmations saturate it and a fourth adds nothing. Worked example: a peer-reviewed paper (p = 0.9) published 18 months ago on a topic with a two-year half-life (r ≈ 0.6) corroborated by two other sources (c = 2, so min(2/3, 1) = 0.667) scores 0.5 · 0.9 + 0.2 · 0.6 + 0.3 · 0.667 = 0.45 + 0.12 + 0.20 = 0.77. A recent but anonymous blog post (p = 0.3, r = 1.0, c = 0) scores only 0.15 + 0.20 + 0 = 0.35, so the loop trusts the paper roughly twice as much and weights its claims accordingly during synthesis.

Coverage is the complement of the gap score. If the planner has identified a set of sub-questions and we mark a sub-question covered once it has at least one finding whose credibility clears a floor (say 0.5), then the gap score is the uncovered fraction and coverage is one minus it:

gap_score = uncovered_subquestions / total_subquestions,   coverage = 1 − gap_score

Worked example: a research outline with 5 sub-questions where 4 have at least one credible finding gives gap_score = 1 / 5 = 0.2 and coverage = 0.8. With the default coverage_target = 0.8 from Code Fragment 29.3.1b, the loop would stop here; lower the target to 0.6 and it stops one sub-question sooner, raise it to 1.0 and it keeps chasing the last gap until it finds a credible source or burns through max_searches. Because both numbers are computed from the same findings list in a single reflect pass, the stopping decision and the gap list it produces are always consistent with each other, which is the property that makes the quality-control step mechanistic rather than asserted.

29.3.2 Data Analysis Agents

Data analysis agents combine natural language understanding with code execution to answer questions about data. The user asks a question in plain language ("What was our churn rate by cohort last quarter?"), the agent writes Python or SQL code to analyze the data, executes the code in a sandbox, interprets the results, and presents findings with visualizations. This is the code agent pattern from Section 29.1 specialized for analytical workflows.

The key architectural decision is how the agent accesses data. Direct database access (the agent writes SQL) is the most flexible but requires careful security controls to prevent destructive queries. Pre-loaded DataFrames (the agent writes pandas code against data already loaded in the sandbox) are simpler and safer but limit the agent to the pre-loaded data. API-based access (the agent calls analytics APIs) provides the best security but limits the types of analysis possible. Most production deployments use a combination: SQL for data extraction, pandas for analysis, and matplotlib/plotly for visualization.

# Data analysis agent with sandboxed code execution
from e2b_code_interpreter import Sandbox
def analyze_data(question: str, data_description: str) -> dict:
    sandbox = Sandbox()
    # Upload the data to the sandbox
    sandbox.files.write("/data/sales.csv", sales_data)
    # Generate and execute analysis code
    code = llm.invoke(
        f"Write Python code to answer this question about the data:\n"
        f"Question: {question}\n"
        f"Data description: {data_description}\n"
        f"The data is available at /data/sales.csv\n"
        f"Use pandas for analysis and matplotlib for any charts.\n"
        f"Save charts to /output/chart.png\n"
        f"Print the answer clearly at the end."
        )
    result = sandbox.run_code(code.content)
    return {
        "answer": result.text,
        "chart": sandbox.files.read("/output/chart.png") if result.text else None,
        "code": code.content,
        }

from smolagents import CodeAgent, HfApiModel
agent = CodeAgent(
    tools=[], # CodeAgent can write and run pandas/matplotlib natively
    model=HfApiModel(),
    additional_authorized_imports=["pandas", "matplotlib"],
)
result = agent.run(
    "Load /data/sales.csv, compute monthly revenue totals, "
    "and plot a bar chart. Save the chart to /output/chart.png."
)

29.3.3 Scientific Discovery Agents

At the frontier of research agents are systems designed for scientific discovery: generating hypotheses, designing experiments, analyzing results, and proposing new research directions. These agents are being deployed in drug discovery, materials science, and genomics, where the volume of literature and data exceeds any human's ability to synthesize. FutureHouse's Robin agent, for example, can propose novel protein engineering strategies by synthesizing knowledge across thousands of papers.

Scientific agents face unique challenges around reproducibility, uncertainty quantification, and domain expertise. A research agent that confidently states an incorrect finding could waste months of laboratory work. Production scientific agents therefore implement aggressive uncertainty quantification, require citations for every claim, flag when they are extrapolating beyond their training data, and always present findings as hypotheses to be verified rather than conclusions.
