Serving Runtimes (vLLM, TGI, SGLang)

vLLM Deep Dive

1. Installing and Running vLLM

vLLM supports Linux with CUDA 11.8 or later. The simplest installation path is through pip. The following command installs vLLM along with its dependencies.

# Install vLLM (requires CUDA 11.8+ and Linux)
pip install vllm

Once installed, you can verify the installation and check which GPU devices are visible.

import vllm
print(f"vLLM version: {vllm.__version__}")

from vllm import LLM
# This will print available GPU information during model loading

1.1 Offline (Batch) Inference

The simplest way to use vLLM is for offline batch inference, where you have a list of prompts and want to generate completions as fast as possible. The LLM class handles model loading, tokenization, and generation in a single interface.

from vllm import LLM, SamplingParams

# Load the model (downloads from HuggingFace on first run)
llm = LLM(model="meta-llama/Llama-3.1-8B-Instruct")

# Define sampling parameters
sampling_params = SamplingParams(
    temperature=0.7,
    top_p=0.9,
    max_tokens=256,
    stop=["\n\n"],          # Stop generation at double newline
    presence_penalty=0.1,
)

# Batch of prompts to process
prompts = [
    "Explain the difference between TCP and UDP in one paragraph.",
    "Write a Python function to calculate the Fibonacci sequence.",
    "What are the three laws of thermodynamics?",
    "Translate 'Hello, how are you?' into French, German, and Japanese.",
]

# Generate completions (vLLM handles batching internally)
outputs = llm.generate(prompts, sampling_params)

for output in outputs:
    prompt = output.prompt
    generated = output.outputs[0].text
    print(f"Prompt:  {prompt[:60]}...")
    print(f"Output:  {generated[:200]}")
    print()

Behind the scenes, vLLM applies PagedAttention and continuous batching to process all four prompts concurrently, fully utilizing the GPU. On an A100 GPU, this batch completes roughly 8x faster than sequential model.generate() calls.

1.2 Sampling Parameters

The SamplingParams class provides fine-grained control over text generation. The table below summarizes the most commonly used parameters.

2. The OpenAI-Compatible Server

vLLM ships with a built-in HTTP server that mirrors the OpenAI Chat Completions and Completions API. This means you can point any application that uses the OpenAI Python SDK at your local vLLM instance by changing the base_url. No other code changes are needed.

To start the server, use the vllm serve CLI command.

# Start the OpenAI-compatible server
vllm serve meta-llama/Llama-3.1-8B-Instruct \
    --host 0.0.0.0 \
    --port 8000 \
    --max-model-len 4096 \
    --gpu-memory-utilization 0.90 \
    --dtype auto

Once the server is running, you can send requests using curl or any HTTP client. The following example demonstrates using the OpenAI Python SDK to chat with the locally hosted model.

from openai import OpenAI

# Point the OpenAI client at the local vLLM server
client = OpenAI(
    base_url="http://localhost:8000/v1",
    api_key="not-needed",  # vLLM does not require an API key by default
)

# Use the standard Chat Completions API
response = client.chat.completions.create(
    model="meta-llama/Llama-3.1-8B-Instruct",
    messages=[
        {"role": "system", "content": "You are a helpful coding assistant."},
        {"role": "user", "content": "Write a binary search function in Python."},
    ],
    temperature=0.3,
    max_tokens=512,
)

print(response.choices[0].message.content)

3. Model Loading and Configuration

vLLM can load models from Hugging Face Hub, local directories, or S3-compatible storage. The LLM constructor and the vllm serve CLI accept several important configuration flags that control memory usage and performance.

from vllm import LLM

# Load a quantized model with tensor parallelism across 2 GPUs
llm = LLM(
    model="TheBloke/Llama-2-70B-Chat-GPTQ",
    quantization="gptq",
    tensor_parallel_size=2,        # Shard across 2 GPUs
    gpu_memory_utilization=0.85,   # Reserve 15% for overhead
    max_model_len=4096,            # Maximum context length
    dtype="float16",               # Use FP16 for non-quantized layers
    trust_remote_code=True,        # Required for some custom models
)

4. Benchmarking vLLM Throughput

vLLM includes a built-in benchmarking script that measures tokens per second for both prefill (prompt processing) and decode (token generation) phases. The following command benchmarks the server with synthetic requests.

# Benchmark with 100 requests, input length 512, output length 128
python -m vllm.entrypoints.openai.api_server &

python -m vllm.benchmark_serving \
    --backend vllm \
    --model meta-llama/Llama-3.1-8B-Instruct \
    --num-prompts 100 \
    --input-len 512 \
    --output-len 128

Typical results on a single A100-80GB GPU for Llama-3.1 8B show throughput of approximately 2,000 to 3,500 output tokens per second with 32 concurrent requests, depending on sequence lengths and quantization settings. This compares to roughly 150 to 300 tokens per second with naive Hugging Face generate().

Summary

vLLM transforms LLM serving into a high-throughput system by combining PagedAttention and continuous batching (both covered in depth in Section 9.3) with an OpenAI-compatible API that makes it a drop-in replacement for cloud-hosted models, enabling local inference with zero code changes. In the next section, we examine Hugging Face's Text Generation Inference (TGI), which takes a different architectural approach to the same serving challenge.

Text Generation Inference (TGI)

1. What Is TGI and When Should You Use It?

Text Generation Inference (TGI) is an open-source serving framework developed by Hugging Face, purpose-built for deploying large language models. Unlike general-purpose model servers such as Triton or TorchServe, TGI is specialized for autoregressive text generation. Its architecture consists of two main components: a Rust-based router that handles HTTP connections, request queuing, and token streaming, and a Python model server that runs the actual inference on GPU using custom CUDA kernels.

TGI is an excellent choice when you need a production-ready serving solution with minimal configuration, when your models are hosted on Hugging Face Hub, or when you want built-in support for features like watermarking, grammar-constrained generation, and speculative decoding. It powers Hugging Face's own Inference Endpoints service, which means it has been tested at significant scale.

2. Docker Deployment

The recommended way to deploy TGI is through its official Docker image. This bundles all CUDA dependencies, the Rust router, and the Python model server into a single container. The following command pulls and runs TGI with a Llama model.

# Pull and run TGI with a Llama 3.1 8B model
docker run --gpus all --shm-size 1g -p 8080:80 \
    -v /data:/data \
    ghcr.io/huggingface/text-generation-inference:latest \
    --model-id meta-llama/Llama-3.1-8B-Instruct \
    --max-input-tokens 2048 \
    --max-total-tokens 4096 \
    --max-batch-prefill-tokens 4096

Let us break down the key parts of this command. The --gpus all flag exposes all host GPUs to the container. The --shm-size 1g flag increases shared memory, which is required for PyTorch's data loader workers. The -v /data:/data mount provides persistent storage for downloaded model weights so they survive container restarts.

2.1 Docker Compose for Persistent Deployments

For production deployments, a Docker Compose file provides a declarative and reproducible setup. The following configuration defines a TGI service with health checks and automatic restarts.

# docker-compose.yml
version: "3.9"

services:
  tgi:
    image: ghcr.io/huggingface/text-generation-inference:latest
    ports:
      - "8080:80"
    volumes:
      - model-cache:/data
    environment:
      - HUGGING_FACE_HUB_TOKEN=${HF_TOKEN}
    deploy:
      resources:
        reservations:
          devices:
            - driver: nvidia
              count: all
              capabilities: [gpu]
    shm_size: "1g"
    command: >
      --model-id meta-llama/Llama-3.1-8B-Instruct
      --quantize awq
      --max-input-tokens 2048
      --max-total-tokens 4096
      --max-concurrent-requests 128
    healthcheck:
      test: ["CMD", "curl", "-f", "http://localhost:80/health"]
      interval: 30s
      timeout: 10s
      retries: 3
    restart: unless-stopped

volumes:
  model-cache:

3. Environment Variables and Configuration

TGI accepts configuration through both command-line arguments and environment variables. Environment variables are prefixed with TGI_ or use Hugging Face-standard names. The table below lists the most important configuration options.

4. Quantization Options

TGI supports several quantization backends that reduce model memory footprint and often increase throughput. You select the quantization method at startup; TGI then loads the model weights in the specified format. The model must have been pre-quantized in the chosen format (with the exception of bitsandbytes, which quantizes on the fly).

# Run with AWQ quantization (model must be pre-quantized)
docker run --gpus all --shm-size 1g -p 8080:80 \
    -v /data:/data \
    ghcr.io/huggingface/text-generation-inference:latest \
    --model-id TheBloke/Llama-2-13B-Chat-AWQ \
    --quantize awq

# Run with bitsandbytes 4-bit quantization (quantizes on the fly)
docker run --gpus all --shm-size 1g -p 8080:80 \
    -v /data:/data \
    ghcr.io/huggingface/text-generation-inference:latest \
    --model-id meta-llama/Llama-3.1-8B-Instruct \
    --quantize bitsandbytes-nf4

5. Making Requests: Streaming and Non-Streaming

TGI exposes two primary HTTP endpoints: /generate for standard request/response and /generate_stream for server-sent events (SSE) streaming. It also provides an OpenAI-compatible endpoint at /v1/chat/completions. The following Python examples demonstrate both modes.

import requests

TGI_URL = "http://localhost:8080"

# Non-streaming request
response = requests.post(
    f"{TGI_URL}/generate",
    json={
        "inputs": "What is the capital of France?",
        "parameters": {
            "max_new_tokens": 100,
            "temperature": 0.7,
            "top_p": 0.9,
            "do_sample": True,
        },
    },
)
result = response.json()
print(result["generated_text"])

For applications that benefit from displaying tokens as they are generated (chatbots, for example), streaming provides a much better user experience. TGI uses server-sent events for its streaming endpoint.

import requests
import json

# Streaming request using server-sent events
response = requests.post(
    f"{TGI_URL}/generate_stream",
    json={
        "inputs": "Explain gradient descent in simple terms.",
        "parameters": {
            "max_new_tokens": 200,
            "temperature": 0.5,
        },
    },
    stream=True,
)

for line in response.iter_lines():
    if line:
        decoded = line.decode("utf-8")
        if decoded.startswith("data:"):
            token_data = json.loads(decoded[5:])
            # Each chunk contains a single token
            if not token_data.get("details"):
                print(token_data["token"]["text"], end="", flush=True)

print()  # Final newline

6. Health Checks and Monitoring

TGI provides health and metrics endpoints that integrate with standard monitoring stacks. The /health endpoint returns HTTP 200 when the model is loaded and ready to serve. The /metrics endpoint exposes Prometheus-format metrics for throughput, latency, and queue depth.

# Check if TGI is healthy
curl http://localhost:8080/health

# Fetch Prometheus metrics
curl http://localhost:8080/metrics

# Key metrics to monitor:
#   tgi_request_duration_seconds    - End-to-end request latency
#   tgi_request_count               - Total requests processed
#   tgi_queue_size                  - Current queue depth
#   tgi_batch_current_size          - Active batch size

7. Router Configuration and Batching Behavior

The Rust router is the entry point for all requests. It maintains a priority queue, groups requests into batches for the model server, and handles backpressure when the system is overloaded. Several parameters control how aggressively the router batches requests.

The router also supports request prioritization and token budgets. When a request exceeds the --max-input-tokens limit, TGI returns an HTTP 422 error immediately rather than attempting to process and fail partway through. This fail-fast behavior prevents wasted GPU cycles.

Summary

TGI provides a Docker-native, production-ready serving solution for LLMs with a clean separation between its Rust networking layer and Python inference layer. Its built-in quantization support, streaming endpoints, health checks, and Prometheus metrics make it well-suited for deployment behind container orchestration systems like Kubernetes. In the next section, we explore SGLang, which takes a fundamentally different approach by providing a programming language for structured LLM interactions.

SGLang

1. Why Another Serving Framework?

vLLM and TGI excel at serving single-turn completions efficiently. However, many real-world LLM applications involve multi-turn interactions, branching logic (generate multiple candidates and pick the best), and structured output constraints (the model must produce valid JSON matching a schema). These patterns require sending many related requests to the server, and traditional serving frameworks treat each request independently, recomputing the KV cache from scratch even when requests share long common prefixes.

SGLang addresses this with two innovations. The frontend DSL lets you express complex LLM programs as Python functions with primitives for generation, selection, branching, and constraints. The RadixAttention backend automatically detects and reuses shared prefixes across requests (see Section 9.3 for the theory). For workloads with high prefix overlap (such as few-shot prompting, retrieval-augmented generation, or multi-turn chat), this can yield 3x to 5x speedups.

2. Installing SGLang

SGLang can be installed from pip. It requires a CUDA-capable GPU and Python 3.9 or later.

# Install SGLang with all dependencies
pip install "sglang[all]"

# Or install just the frontend (for connecting to a remote SGLang server)
pip install sglang

3. The SGLang Frontend DSL

The SGLang frontend provides Python primitives for constructing LLM programs. The key building blocks are gen() for text generation, select() for constrained choice among options, and fork() for parallel branching. The following example demonstrates a structured extraction task.

import sglang as sgl

@sgl.function
def extract_entity(s, text):
    s += sgl.system("You are a precise entity extraction system.")
    s += sgl.user(f"Extract information from this text: {text}")
    s += sgl.assistant(
        "Entity name: " + sgl.gen("name", max_tokens=50, stop="\n")
        + "\nEntity type: " + sgl.select("type", [
            "Person", "Organization", "Location", "Product", "Event"
        ])
        + "\nConfidence: " + sgl.select("confidence", [
            "High", "Medium", "Low"
        ])
    )

# Run the function
runtime = sgl.Runtime(model_path="meta-llama/Llama-3.1-8B-Instruct")
sgl.set_default_backend(runtime)

state = extract_entity.run(text="Apple Inc. announced the new iPhone 16 at their Cupertino headquarters.")

print(f"Name: {state['name']}")
print(f"Type: {state['type']}")
print(f"Confidence: {state['confidence']}")

runtime.shutdown()

Notice how sgl.select() constrains the model to choose from a predefined list rather than generating free-form text. SGLang implements this efficiently by evaluating the log-probabilities of each option in parallel, choosing the one with the highest likelihood. This is both faster and more reliable than prompting the model to pick from a list and then parsing the output.

3.1 Branching with fork()

The fork() primitive creates parallel branches that share the same prefix KV cache. This is useful for generating multiple candidates and selecting the best one, implementing tree-of-thought reasoning, or running A/B tests on different continuations.

@sgl.function
def best_of_n(s, question, n=3):
    s += sgl.system("You are a helpful assistant. Think step by step.")
    s += sgl.user(question)

    # Fork into n parallel branches (all share the prefix KV cache)
    forks = s.fork(n)
    for i, f in enumerate(forks):
        f += sgl.assistant(sgl.gen(f"answer_{i}", max_tokens=300, temperature=0.8))

    # Collect all answers
    answers = [forks[i][f"answer_{i}"] for i in range(n)]
    return answers

4. Structured Output with Constraints

One of SGLang's strongest features is its ability to constrain generation to match a regular expression or JSON schema. This guarantees that the model output is syntactically valid, eliminating the need for retry loops or post-processing. The constraint is applied at the token level during decoding using a finite-state machine.

@sgl.function
def generate_json_record(s, description):
    s += sgl.system("You extract structured data as JSON.")
    s += sgl.user(f"Extract a person record from: {description}")
    s += sgl.assistant(
        sgl.gen(
            "json_output",
            max_tokens=200,
            regex=r'\{"name": "[^"]+", "age": \d+, "city": "[^"]+"\}',
        )
    )

state = generate_json_record.run(
    description="John Smith is a 34-year-old software engineer living in Seattle."
)

import json
record = json.loads(state["json_output"])
print(record)
# Output: {"name": "John Smith", "age": 34, "city": "Seattle"}

5. RadixAttention in Practice

RadixAttention is the backend optimization that makes SGLang's frontend primitives fast. When a new request arrives, the SGLang server walks its radix tree of cached KV states to find the longest matching prefix and reuses those states, avoiding redundant computation.

6. Server Deployment

SGLang provides a server mode that exposes both its native API and an OpenAI-compatible API. The server can be launched from the command line.

# Launch the SGLang server
python -m sglang.launch_server \
    --model-path meta-llama/Llama-3.1-8B-Instruct \
    --port 30000 \
    --tp 1 \
    --mem-fraction-static 0.85

Once the server is running, you can connect to it using the SGLang client or any OpenAI-compatible client library.

from openai import OpenAI

# Connect to SGLang's OpenAI-compatible endpoint
client = OpenAI(base_url="http://localhost:30000/v1", api_key="none")

response = client.chat.completions.create(
    model="meta-llama/Llama-3.1-8B-Instruct",
    messages=[
        {"role": "system", "content": "You are a helpful assistant."},
        {"role": "user", "content": "Explain RadixAttention in two sentences."},
    ],
    temperature=0.3,
    max_tokens=100,
)
print(response.choices[0].message.content)

7. Batch Inference with SGLang

For offline batch processing, SGLang provides efficient parallel execution that automatically exploits prefix sharing across the batch. The following example processes a batch of classification tasks.

@sgl.function
def classify_sentiment(s, review):
    s += sgl.system("Classify the sentiment of the following review.")
    s += sgl.user(review)
    s += sgl.assistant(
        "Sentiment: " + sgl.select("sentiment", ["Positive", "Negative", "Neutral"])
    )

# Process a batch of reviews
reviews = [
    "This product exceeded my expectations! Highly recommend.",
    "Terrible quality. Broke after one day.",
    "It works fine. Nothing special, nothing terrible.",
    "Best purchase I've made all year!",
    "Would not buy again. Very disappointing.",
]

# Run batch (SGLang automatically shares the system prompt KV cache)
states = classify_sentiment.run_batch(
    [{"review": r} for r in reviews],
    progress_bar=True,
)

for review, state in zip(reviews, states):
    print(f"{state['sentiment']:>10} | {review[:60]}")

Summary

SGLang bridges the gap between serving infrastructure and application logic by providing a Python DSL for composing complex LLM programs. Its RadixAttention backend automatically detects and reuses shared prefixes across requests, delivering significant speedups for workloads with prefix overlap. The constrained generation features (regex, JSON schema, select) guarantee structurally valid outputs without post-processing. In the next section, we examine the quantization techniques that reduce model size and increase throughput across all three serving frameworks.
