When to Retrieve, When to Reason

"The model knows everything in its weights. Retrieval is for everything else."

RAG, Retrieval-Reasoning AI Agent

33.3.1 The Four Patterns

Four production patterns cover the multimodal query space:

• Direct VLM: send the query (and any user-provided images) to a frontier multimodal model; trust its trained knowledge. Cheapest at the per-query level but limited to whatever the model has learned.
• Static RAG: retrieve top-k from a pre-built multimodal index, splice into the VLM prompt. The pattern from Section 33.2. Use for private or domain-specific corpora.
• Hybrid (RAG + reasoning): VLM first decides whether retrieval is needed (a "self-RAG" pattern); only fetches when its confidence is low or the query mentions specific entities.
• Agentic search: the VLM uses tools (web search, internal database, image search) iteratively to assemble context, similar to Section 37.1's agent patterns extended to multimodal queries.

33.3.2 When Direct VLM Wins

Skip retrieval and answer with the VLM directly when:

• The query is self-contained: the user uploads an image and asks "what's in this picture?" No retrieval can improve on what the VLM sees directly.
• The knowledge is well within the model's training: identifying common objects, places, plants, animals; basic image manipulation requests; general factual visual questions.
• Latency budget is tight: an extra retrieval round-trip adds 100 to 500 ms; in real-time applications (voice agents, AR overlays), that may be unaffordable.
• Cost matters more than absolute quality: direct VLM is the cheapest pattern per query.

The empirical rule of thumb: if a knowledgeable human could answer your query just by looking at the image, the VLM probably can too. Save retrieval for queries that would stump that human without access to specific documents.

33.3.3 When RAG Wins

Reach for retrieval when the VLM cannot have seen the answer:

• The answer is in private content: company documents, proprietary images, internal video archives. The VLM has never seen these.
• The content is time-sensitive: news photos, stock charts, current events imagery. The VLM's training cutoff is months to years stale.
• You need source attribution: regulatory or audit contexts where you must show which document or image the answer came from.
• Specific entities matter: "find me Dr. Smith's report on patient 12345" requires precise retrieval, not the VLM's parametric memory.
• The corpus is too large for in-context: a 100k-image catalog cannot fit in any prompt, so retrieval is forced.

33.3.4 When Hybrid Wins

Hybrid patterns (the VLM decides whether to retrieve) win when:

• Your traffic is mixed: some queries need retrieval, others don't. Routing avoids paying retrieval cost on every query.
• You have a budget for false positives: occasionally retrieving when you shouldn't have is fine, as long as you don't miss the cases where retrieval would have helped.
• The model can reliably self-assess: modern VLMs (GPT-4o, Gemini 2.5) are fairly good at recognizing "I don't know this" or "I would need to look this up", which makes the routing layer simpler.

The simplest hybrid is a router prompt: ask the VLM "should I retrieve external context to answer this, or do I have enough to answer directly?" before generating the final answer. Cost adds ~100 tokens per query; quality benefit on knowledge-heavy queries is substantial.

# A hybrid router that decides retrieve vs reason per query.
# Uses GPT-4o-mini to classify, then dispatches accordingly.
from openai import OpenAI
oai = OpenAI()

ROUTER_PROMPT = """Decide if answering this query needs retrieval over the user's
private image and document corpus, or if the question can be answered
from general knowledge and the directly attached media.

Respond with exactly one of:
  DIRECT  -- answerable from VLM knowledge and attached media
  RAG     -- needs retrieval from the private corpus
  AGENT   -- needs iterative search across multiple tools

Query: {query}"""

def route_and_answer(query, attachments=None):
    # 1. Decide the path
    classification = oai.chat.completions.create(
        model="gpt-4o-mini",
        messages=[{"role": "user",
                   "content": ROUTER_PROMPT.format(query=query)}],
        max_tokens=10,
    ).choices[0].message.content.strip().upper()
    # 2. Dispatch
    if "DIRECT" in classification:
        return answer_direct(query, attachments)
    elif "RAG" in classification:
        retrieved = multimodal_rag_retrieve(query, k=5)
        return answer_with_context(query, attachments, retrieved)
    else:  # AGENT
        return agent_search(query, attachments)

33.3.5 When Agentic Search Wins

Agentic search is the right choice when:

• The query is complex and multi-hop: "Find me images of solar panel installations in Texas that were completed after January 2025 and have published efficiency metrics" requires combining multiple retrievals.
• The corpus is partitioned: different tools index different content (web image search, internal photo archive, regulatory database). Agent decides which to use.
• The query may require iterative refinement: the VLM looks at first-pass results, recognizes they're insufficient, and reformulates the query.

Agentic search is the most expensive pattern (multiple tool calls per query, longer latency) but produces the highest-quality answers on open-ended tasks. The 2025-2026 production pattern combines Gemini 2.5 Pro's native tool-use with a small set of multimodal-aware tools (image search, document RAG, web search).

33.3.6 The Cost-Quality Frontier

33.3.7 Debugging the Choice

Picking the right pattern is empirical. A practical workflow:

1. Start with direct VLM as the baseline.
2. Collect 100 to 200 representative production queries.
3. Label each query with the "correct" pattern (a human reviews and decides).
4. Measure accuracy of direct VLM vs RAG vs hybrid on this labeled set.
5. Choose the pattern that hits your quality target at the lowest cost.

For production monitoring, instrument the router with the chosen pattern, the user's downstream feedback (thumbs up/down), and any retrieval hit-rate metrics. Over time, you can adapt the router thresholds based on which patterns produce satisfactory outcomes.

33.3.8 The Router as a Policy

The router is not just a static prompt. In production, it can be:

• Rule-based: if query mentions a private entity, RAG; else, direct.
• Prompt-based: ask the VLM to classify (the simplest pattern, Code Fragment 33.3.1b).
• Confidence-based: run direct VLM first; if its confidence (or self-rated confidence) is low, fall back to RAG.
• Learned: a small classifier trained on query features and downstream outcome signals (clicks, thumbs up).

The 2026 production default is prompt-based for systems under 1M queries/day (engineering simplicity) and learned for high-volume systems where the router's accuracy directly affects cost.
